Dell Latitude D520 User Manual

5. Disconnect the modem cable from the modem.
Replacing the Modem

1. Connect the modem cable to the modem.

2. Connect the modem to the system board.
Align the connector on the bottom of the modem with the modem connector on the system board, and press down on the right side of the modem.

3. Replace the M2 x 3-mm screw.
Back to Contents Page

NOTICE: Ensure that the modem cable is routed correctly when you replace the modem.

Dell Latitude D520 Specifications

General

Processor	Intel Core Duo or Intel Celeron M
Graphics	Intel Graphics Media Accelerator 950
Operating System	Windows XP Professional
Chipset	Intel 945GM Express
Maximum Memory	4 GB
Processor Speed	1.66 GHz
RAM	512 MB to 4 GB
Storage	40 GB to 120 GB HDD
Display	15.4 inch
Display Resolution	1280 x 800 (WXGA)
Optical Drive	DVD-ROM
Battery	6-cell Lithium Ion
Ports	4 x USB 2.0, VGA, Ethernet, Modem
Wireless	802.11a/b/g
