9 SCG1000 | Dell Networking S4810 and Force10 S4810 Configuration Guide for EqualLogic SANs
2.9 Configure spanning tree on edge ports
FTOS(conf-if-range-te-0/0-47)#spanning-tree rstp edge-port
FTOS(conf-if-range-te-0/0-47)#exit
FTOS(conf)#protocol spanning-tree rstp
FTOS(conf-rstp)#no disable
FTOS(conf-rstp)#exit
2.10 Configure port channel for LAG
These commands configure the switch interconnect as a LAG.
FTOS(conf)#interface Port-channel 1
FTOS(conf-if-po-1)#mtu 12000
FTOS(conf-if-po-1)#switchport
FTOS(conf-if-po-1)#no shutdown
FTOS(conf-if-po-1)#exit
2.11 Configure QSFP ports for LAG
These commands assigns 40Gb QSFP ports to the Port Channel.
FTOS(conf)#interface range fortyGigE 0/48 , fortyGigE 0/52
FTOS(conf-if-range-fo-0/48,fo-0/52)#no ip address
FTOS(conf-if-range-fo-0/48,fo-0/52)#mtu 12000
FTOS(conf-if-range-te-0/48,fo-0/52)#no shutdown
FTOS(conf-if-range-fo-0/48,fo-0/52)#flowcontrol rx on tx off
FTOS(conf-if-range-fo-0/48,fo-0/52)#port-channel-protocol lacp
FTOS(conf-if-range-fo-0/48,fo-0/52-lacp)#port-channel 1 mode active
FTOS(conf-if-range-fo-0/48,fo-0/52-lacp)#exit
FTOS(conf-if-range-fo-0/48,fo-0/52)#exit
FTOS(conf)#exit
2.12 Save configuration
FTOS#copy running-config startup-config
2.13 Configure additional switch
Repeat the commands from section 2 to configure the second switch.
Note: The preceding procedure places all switch ports in the default VLAN. If you prefer to place ports in
a non-default VLAN, refer to the documentation for your switch.
