Dell OptiPlex 3010 User Manual

8. Slide the I/O panel towards the right of the computer to release it from the chassis.
9. Remove the I/O panel.
Related Links
Installing The Input/Output (I/O) Panel
Installing The Input/Output (I/O) Panel
1. Insert the I/O panel into the slot on the chassis front.
2. Slide the I/O panel towards the left of the computer to secure to the chassis.
3. Tighten the screw to secure the I/O panel to the chassis.
4. Connect the I/O panel or the FlyWire cable to the system board.
5. Thread the I/O panel or the FlyWire cable into the fan-shelter clip and the routing on the heat sink.
6. Install the drive cage.
7. Install the front bezel.
8. Install the cover.
9. Follow the procedures in After Working Inside Your Computer.
25

Dell OptiPlex 3010 Specifications

General

Tcase	69.1 °C
Bus type	DMI
Processor cache	3 MB
Processor cores	2
Processor model	i3-2120
System bus rate	5 GT/s
Processor family	Intel® Core™ i3
Processor series	Intel Core i3-2100 Desktop Series
Processor socket	LGA 1155 (Socket H2)
Processor threads	4
Processor codename	Sandy Bridge
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	65 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	33
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3 1066/1333
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
Product type	PC
Motherboard chipset	Intel® H61
Memory slots	1x DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	1 x 4 GB
HDD size	3.5 \
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	DVD±RW
Total storage capacity	250 GB
HDMI	Yes
Networking features	Gigabit Ethernet
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
On-board graphics card ID	0x102
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 2000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	850 MHz
On-board graphics card dynamic frequency (max)	1100 MHz
Operating system installed	Windows 7 Professional
Serial ports quantity	-
USB 2.0 ports quantity	8
Firewire (IEEE 1394) ports	0
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Chassis type	SFF
Product color	Aluminium, Black
Certification	CECP, AEEA, BvGS
Sustainability certificates	EPEAT Gold, ENERGY STAR
Power supply	240 W
Processor ARK ID	53426
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	312 mm
Width	93 mm
Height	290 mm
Weight	5700 g
