Dell OptiPlex 5250 User Manual

Troubleshooting your computer
You can troubleshoot your computer using indicators like diagnostic lights, beep codes, and error messages during the operation of the
computer.
Enhanced Pre-Boot System Assessment (ePSA)
diagnostics
The ePSA diagnostics (also known as system diagnostics) performs a complete check of your hardware. The ePSA is embedded with the
BIOS and is launched by the BIOS internally. The embedded system diagnostics provides a set of options for particular devices or device
groups allowing you to:
• Run tests automatically or in an interactive mode
• Repeat tests
• Display or save test results
• Run thorough tests to introduce additional test options to provide extra information about the failed device(s)
• View status messages that inform you if tests are completed successfully
• View error messages that inform you of problems encountered during testing
CAUTION
: Use the system diagnostics to test only your computer. Using this program with other computers may cause invalid
results or error messages.
NOTE: Some tests for specic devices require user interaction. Always ensure that you are present at the computer terminal
when the diagnostic tests are performed.
Running the ePSA diagnostics
1 Power-on the computer.
2 As the computer boots, press the F12 key as the Dell logo appears.
3 On the boot menu screen, select the Diagnostics option.
The Enhanced Pre-boot System Assessment window is displayed, listing all devices detected in the computer. The diagnostics starts
running the tests on all the detected devices.
4 To run a diagnostic test on a specic device, press Esc and click Yes to stop the diagnostic test.
5 Select the device from the left pane and click Run Tests.
6 If there are any issues, error codes are displayed.
Note the error code and contact Dell.
Power supply—built in self test (BIST)
ships with a power supply with the built in self-test (BIST) feature that drives new troubleshooting steps for customers and technicians. All
power supply units include a self-test ability in an isolation mode.
Customers can test the health of the power system by pressing the test button. The button is lit by a signal in the power supply called
Power_Good (PG). When the +3.3v, +5v, and +12v rails are up and within spec, the PG signal turns on, lighting the self-test LED. By
removing the cable harness in units that do not pass this test, the customer, or technician can isolate the failure's cause to an attached
device of the power supply.
5
58 Troubleshooting your computer

Dell OptiPlex 5250 Specifications

General

Screen shape	Flat
LED backlight	Yes
Display diagonal	21.5 \
Tilt angle range	-5 - 30 °
Native aspect ratio	16:9
Bus type	DMI3
Stepping	B0
Tjunction	100 °C
Processor code	SR335
Processor cache	6 MB
Processor cores	4
Processor model	i5-7500
System bus rate	8 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-7500 Desktop Series
Processor socket	LGA 1151 (Socket H4)
Processor codename	Kaby Lake
Number of QPI links	0
Processor frequency	3.4 GHz
Processor cache type	Smart Cache
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	3.8 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 1x8+2x4, 2x8
Thermal Design Power (TDP)	65 W
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3L-SDRAM, DDR4-SDRAM
Memory voltage supported by processor	1.35 V
Memory channels supported by processor	Dual
Memory clock speeds supported by processor	1333, 1600, 2133, 2400 MHz
Maximum internal memory supported by processor	64 GB
On-board graphics card ID	5912
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 630
On-board graphics card family	Intel® HD Graphics
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1100 MHz
Number of displays supported (on-board graphics)	3
Memory slots	2
Internal memory	4 GB
Memory slots type	SO-DIMM
Memory clock speed	2400 MHz
Memory form factor	DIMM/SO-DIMM
Internal memory type	DDR4-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	1 x 4 GB
HDD speed	7200 RPM
HDD interface	SATA III
Storage media	HDD
Optical drive type	DVD±RW
Total storage capacity	500 GB
Compatible memory cards	SD
Number of storage drives installed	1
Total megapixels	2 MP
Audio system	Waves MaxxVoice Pro
RMS rated power	7.6 W
Speakers manufacturer	Waves
Optical drive interface	SATA
Product type	All-in-One PC
Market positioning	Business
Motherboard chipset	Intel® Q270
Placement supported	Vertical
Product color	Black
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Trial software	Microsoft Office
Operating system language	Multilingual
Operating altitude	0 - 5000 m
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
AC adapter frequency	47/63 Hz
AC adapter input voltage	90 - 264 V
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Scalability	1S
Processor ARK ID	97123
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal solution specification	PCG 2015C
Intel Identity Protection Technology version	1.00
Sustainability certificates	RoHS, ENERGY STAR
Certification	EPEAT, TCO, CEL, WEEE

Weight and Dimensions

Depth (with stand)	60.9 mm
Width (with stand)	527.8 mm
Height (with stand)	363 mm
Weight (with stand)	6320 g
