Dell OptiPlex 7050 User Manual

Verifying system memory in Windows 10 and Windows
7
Windows 10
1 Click the Windows button and select All Settings > System.
2 Under System, click About.
Windows 7
• Click Start → Control Panel → System.
Verifying system memory in setup
1 Turn on or restart your computer..
2 Perform one of the following actions after the Dell logo is displayed:
• With keyboard — Tap F2 until the Entering BIOS setup message appears. To enter the Boot selection menu, tap F12.
3 On the left pane, select Settings > General > System Information,
The memory information is displayed on the right pane.
Testing memory using ePSA
1 Turn on or restart your computer.
2 After the Dell logo is displayed:
a Press F12.
b Select ePSA diagnostics
The PreBoot System Assessment (ePSA) starts on your computer.
NOTE
: If you wait too long and the operating system logo appears, continue to wait until you see the desktop. Turn o
the computer and try again.
USB features
The Universal Serial Bus, or well known as USB was introduced to the PC world in 1996 which dramatically simplied the connection
between host computer and peripheral devices such as mice and keyboards, external hard drive or optical devices, Bluetooth and many
more peripheral devices in the market.
Let's take a quick look on the USB evolution referencing to the table below.
Table 1. USB evolution
Type Data Transfer Rate Category Introduction Year
USB 3.0/USB 3.1 Gen 1 5 Gbps Super Speed 2010
USB 2.0 480 Mbps High Speed 2000
24 Technology and components

Dell OptiPlex 7050 Specifications

General

Bus type	DMI3
Stepping	B0
Tjunction	100 °C
Processor cache	6 MB
Processor cores	4
Processor model	i5-7500
System bus rate	8 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-7500 Desktop Series
Processor socket	LGA 1151 (Socket H4)
Processor codename	Kaby Lake
Number of QPI links	0
Processor frequency	3.4 GHz
Processor cache type	Smart Cache
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	3.8 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 1x8+2x4, 2x8
Thermal Design Power (TDP)	65 W
Number of processors installed	1
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3L-SDRAM, DDR4-SDRAM
Memory voltage supported by processor	1.35 V
Memory clock speeds supported by processor	1333, 1600, 2133, 2400 MHz
Maximum internal memory supported by processor	64 GB
On-board graphics card	Yes
On-board graphics card ID	5912
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 630
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1100 MHz
Number of displays supported (on-board graphics)	3
Memory slots	4x DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	2400 MHz
Internal memory type	DDR4-SDRAM
Memory layout (slots x size)	1 x 4 GB
HDD size	3.5 \
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD±RW
Total storage capacity	500 GB
Trial software	Microsoft Office
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	-
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	5
Chassis type	SFF
Product color	Black
Placement supported	Horizontal/Vertical
Audio chip	Realtek ALC3234
Product type	PC
Password protection type	BIOS, Supervisor, User
Power supply	180 W
Power supply input voltage	90 - 264 V
Power supply input frequency	47/63 Hz
Operating altitude	-15.2 - 3048 m
Non-operating altitude	-15.2 - 10668 m
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	AC
Scalability	1S
Processor code	SR335
Processor ARK ID	97123
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal solution specification	PCG 2015C
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	292.1 mm
Width	92.71 mm
Height	290.06 mm
Weight	5140 g
