Power button with fingerprint reader (optional)
Removing the power button with fingerprint reader (optional)
Prerequisites
NOTE: This procedure is only applicable to computers shipped with a power button with fingerprint reader.
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
3. Remove the battery.
4. Remove the fan.
5. Remove the I/O board.
About this task
The following image indicates the location of the power button with fingerprint reader and provides a visual representation of
the removal procedure.
48 Removing and installing components
