Electrical Specifications
Model P2214H/P2414H
Video input signals • Analog RGB, 0.7 Volts +/- 5%, positive polarity at
75 ohm input impedance
• Digital DVI-D TMDS, 600 mV for each differential
line, positive polarity at 50 ohm input impedance
• DP 1.2 signal input support*
Synchronization input signals Separate horizontal and vertical synchronizations,
polarity-free TTL level, SOG (Composite SYNC on
green)
AC input voltage/frequency/
current
100 VAC to 240 VAC / 50 Hz or 60 Hz + 3 Hz / 1.2 A
(typical)
Inrush current • 120 V: 30 A (Max)
• 240 V: 60 A (Max)
*Support DP1.2 (CORE) specification. Excludes High Bit Rate 2 (HBR2), Fast AUX
transaction, Multi-stream transport (MST), 3D stereo transport, HBR Audio (or high data
rate audio)
Physical Characteristics
Model P2214H P2414H
Connector type 15-pin D-subminiature,
blue connector; DVI-D,
white connector; DP, black
connector
15-pin D-subminiature,
blue connector; DVI-D,
white connector; DP, black
connector
Signal cable type • Digital: detachable, DVI-
D, solid pins, shipped
detached from the
monitor
• Digital: DisplayPort, 20
pin
• Analog: attachable, D-
Sub, 15 pins, shipped
attached to the monitor
• Digital: detachable, DVI-
D, solid pins, shipped
detached from the
monitor
• Digital: DisplayPort, 20
pin
• Analog: attachable, D-
Sub, 15 pins, shipped
attached to the monitor
Dimensions (with stand)
Height (extended) 483.6 mm (19.04 inches) 499.0 mm (19.65 inches)
Height (compressed) 354.2 mm (13.94 inches) 369.0 mm (14.53 inches)
Width 512.7 mm (20.19 inches) 565.6 mm (22.27 inches)
12 | About Your Monitor
