Dell P2422H User Manual

12 │ About your monitor
Bottom view
73 654 8 821
Bottom view without monitor stand
Label Description Use
1 Security-lock slot Secure your monitor using a security lock
(purchased separately) to prevent unauthorized
movement of your monitor.
2 Power connector Connect the power cable (shipped with your
monitor).
3 HDMI port Connect to your computer using a HDMI cable
(shipped with your monitor, for Brazil only).
4 Stand lock To lock the stand to the monitor using a M3 x 6
mm screw (screw not included).
5 DisplayPort Connect to your computer using a DisplayPort
cable (shipped with your monitor).
6 VGA connector Connect your computer with VGA cable (shipped
with your monitor, for Japan only).
7 USB 3.0 upstream
port
Connect the USB cable (shipped with your
monitor) from this port to your computer to
enable the USB ports on your monitor.
8 SuperSpeed USB 5
Gbps (USB3.2 Gen 1)
Type-A downstream
port (4)
Connect your USB devices. *
NOTE: To use this port, you must
connect the USB upstream cable
(shipped with your monitor) between the
monitor and the computer.
*To avoid signal interference, when a wireless USB device has been connected
to a USB downstream port, it is NOT recommended to connect any other USB
devices to the adjacent port(s).

Dell P2422H Specifications

General

Color depth	6 bit
Pixel pitch	0.2745 x 0.2745 mm
Screen shape	Flat
Pixel density	93 ppi
Response time	8 ms
Backlight type	LED
Display diagonal	23.8 \
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	50 - 76 Hz
Maximum refresh rate	60 Hz
Response time (fast)	5 ms
Horizontal scan range	30 - 83 kHz
Supported video modes	480p, 576p, 720p, 1080i, 1080p
Viewable size diagonal	604.7 mm
Viewable size, vertical	296.46 mm
sRGB coverage (typical)	99 %
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	60.47 cm
Viewable size, horizontal	527.04 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDMI version	1.4
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
DVI-D ports quantity	0
USB upstream port type	USB Type-B
USB Type-A downstream ports quantity	4
Pivot angle	-90 - 90 °
LED indicators	Power
Tilt angle range	-5 - 21 °
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
Power supply type	Internal
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	48 W
Power consumption (off)	0.2 W
Power consumption (standby)	0.3 W
Power consumption (typical)	11.8 W
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %
RMS rated power	0 W
Package weight	7950 g
Feet color	Silver
Product color	Black
Heavy metals free	Hg (mercury)
Market positioning	Business
Cables included	AC, DisplayPort, USB
Doesn't contain	PVC/BFR
Sustainability certificates	ENERGY STAR, EPEAT Gold, RoHS
Harmonized System (HS) code	85285210

Weight and Dimensions

Bezel width (top)	5.38 mm
Depth (with stand)	179.57 mm
Width (with stand)	537.8 mm
Height (with stand)	496.11 mm
Weight (with stand)	5150 g
Bezel width (bottom)	16.66 mm
Depth (without stand)	52.15 mm
Height (without stand)	318.5 mm
Weight (without stand)	3390 g
