Dell P2422H User Manual

60 │ Operating your monitor
The Power Warning Message box below shall apply to Brightness functions for
the first time when user adjust the Brightness level above the default level.
default level. Do you want to continue?
Yes
Adjusting to this value will increase power consumption above the
No
When Factory Reset is selected, the following message appears:
Are you sure you want to reset to default settings?
Yes
No
When you select ‘Yes’ to reset to default settings, the following message will
appear:
2X Monitor
Select ‘Yes’ to enable the following function(s):
·
Yes
USB Charging
No
See Troubleshooting for more information.

Dell P2422H Specifications

General

Color depth	6 bit
Pixel pitch	0.2745 x 0.2745 mm
Screen shape	Flat
Pixel density	93 ppi
Response time	8 ms
Backlight type	LED
Display diagonal	23.8 \
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	50 - 76 Hz
Maximum refresh rate	60 Hz
Response time (fast)	5 ms
Horizontal scan range	30 - 83 kHz
Supported video modes	480p, 576p, 720p, 1080i, 1080p
Viewable size diagonal	604.7 mm
Viewable size, vertical	296.46 mm
sRGB coverage (typical)	99 %
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	60.47 cm
Viewable size, horizontal	527.04 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDMI version	1.4
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
DVI-D ports quantity	0
USB upstream port type	USB Type-B
USB Type-A downstream ports quantity	4
Pivot angle	-90 - 90 °
LED indicators	Power
Tilt angle range	-5 - 21 °
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
Power supply type	Internal
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	48 W
Power consumption (off)	0.2 W
Power consumption (standby)	0.3 W
Power consumption (typical)	11.8 W
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %
RMS rated power	0 W
Package weight	7950 g
Feet color	Silver
Product color	Black
Heavy metals free	Hg (mercury)
Market positioning	Business
Cables included	AC, DisplayPort, USB
Doesn't contain	PVC/BFR
Sustainability certificates	ENERGY STAR, EPEAT Gold, RoHS
Harmonized System (HS) code	85285210

Weight and Dimensions

Bezel width (top)	5.38 mm
Depth (with stand)	179.57 mm
Width (with stand)	537.8 mm
Height (with stand)	496.11 mm
Weight (with stand)	5150 g
Bezel width (bottom)	16.66 mm
Depth (without stand)	52.15 mm
Height (without stand)	318.5 mm
Weight (without stand)	3390 g
