About your monitor 13
Monitor specifications
Model P2720D
Screen type Active matrix-TFT LCD
Panel type In-Plane Switching Technology
Viewable image
Diagonal
Horizontal, Active Area
Vertical, Active Area
Area
684.70 mm (27.0 in.)
596.74 mm (23.49 in.)
335.66 mm (13.76 in.)
200,301.75 mm
2
(323.22 in.
2
)
Pixel pitch 0.233 mm x 0.233 mm
Pixel per inch (PPI) 108
Viewing angle
Horizontal
Vertical
178° (typical)
178° (typical)
Luminance output 350 cd/m² (typical)
Contrast ratio 1000 to 1 (typical)
Faceplate coating Anti-glare with 3H hardness, Haze 25%
Backlight LED edgelight system
Response time (Gray to
Gray)
8 ms (Normal)
5 ms (Fast)
Color depth 1.67 billion colors
Color gamut 99% sRGB
Connectivity 1 x HDMI 1.4
1 x DP 1.2
1 x USB 3.0 upstream
2 x USB 3.0 port - Side
2 x USB 2.0 port - Bottom

Other manuals for Dell P2720D

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dell P2720D and is the answer not in the manual?

Dell P2720D Specifications

General IconGeneral
Doesn't containBRF, PVC
Sustainability certificatesRoHS, ENERGY STAR
Feet colorBlack/Silver
CertificationTCO, NFPA 99
Product colorBlack
Market positioningBusiness
Pivot angle-90 - 90 °
Tilt angle range-5 - 21 °
Panel mounting interface100 x 100 mm
3DNo
Color gamut99 %
Pixel pitch0.233 x 0.233 mm
Screen shapeFlat
Pixel density108 ppi
Response time8 ms
Backlight typeLED
Display diagonal27 \
Display technologyLCD
Native aspect ratio16:9
Vertical scan range49 - 75 Hz
Maximum refresh rate60 Hz
Response time (fast)5 ms
Horizontal scan range29 - 113 kHz
Supported video modes480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 1440p
Viewable size diagonal684.7 mm
Viewable size, vertical335.66 mm
Contrast ratio (typical)1000:1
Display number of colors16.78 million colors
Viewable size, horizontal596.74 mm
Display brightness (typical)350 cd/m²
Supported graphics resolutions640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1280 x 768 (WXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2048 x 1080, 2560 x 1440
HDMI version1.4
USB hub version2.0 / 3.2 Gen 1 (3.1 Gen 1)
DisplayPort version1.2
USB upstream port typeUSB Type-B
Number of upstream ports1
VGA (D-Sub) ports quantity0
USB Type-A downstream ports quantity4
Current rating1.6 A
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Energy efficiency scaleA to G
Power consumption (max)55 W
Power consumption (standby)0.2 W
Power consumption (typical)21.7 W
Power consumption (PowerSave)19 W
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)10 - 80 %
Cables includedAC, DisplayPort, USB
Package depth690.12 mm
Package width424.94 mm
Package height169.93 mm
Package weight9130 g
Harmonized System (HS) code85285210
Weight and Dimensions IconWeight and Dimensions
Bezel width (top)7.4 mm
Depth (with stand)185 mm
Width (with stand)611.6 mm
Height (with stand)525.3 mm
Weight (with stand)6420 g
Bezel width (bottom)21.1 mm
Depth (without stand)43.6 mm
Height (without stand)364.1 mm
Weight (without stand)4570 g
