Dell P2720D User Manual

Operating your monitor │ 47
OSD warning messages
When the monitor does not support a particular resolution mode, the following
message is displayed:
The current input timing is not supported by the monitor display.
Please change your input timing to 2560x1440, 60Hz or any other
monitor listed timing as per the monitor specications.
Dell 27 Monitor
This means that the monitor cannot synchronize with the signal that it is receiving
from the computer. See Monitor specifications for the Horizontal and Vertical
frequency ranges addressable by this monitor. Recommended mode is 2560 x
1440.
Before the DDC/CI function is disabled, the following message is displayed:
The function of adjusting display setting using PC application will be
disabled.
Do you wish to disable DDC/CI function?
Yes
No
Dell 27 Monitor
P2720D
When the monitor enters the Power Save Mode, the following message appears:
Dell P2418HZ
Dell 27 Monitor
Entering Power Save Mode.
P2720D
If you press any button other than the power button, the following messages will
appear depending on the selected input:

Dell P2720D Specifications

General

Doesn't contain	BRF, PVC
Sustainability certificates	RoHS, ENERGY STAR
Feet color	Black/Silver
Certification	TCO, NFPA 99
Product color	Black
Market positioning	Business
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 21 °
Panel mounting interface	100 x 100 mm
3D	No
Color gamut	99 %
Pixel pitch	0.233 x 0.233 mm
Screen shape	Flat
Pixel density	108 ppi
Response time	8 ms
Backlight type	LED
Display diagonal	27 \
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	49 - 75 Hz
Maximum refresh rate	60 Hz
Response time (fast)	5 ms
Horizontal scan range	29 - 113 kHz
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 1440p
Viewable size diagonal	684.7 mm
Viewable size, vertical	335.66 mm
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	596.74 mm
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1280 x 768 (WXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2048 x 1080, 2560 x 1440
HDMI version	1.4
USB hub version	2.0 / 3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
USB upstream port type	USB Type-B
Number of upstream ports	1
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	4
Current rating	1.6 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	55 W
Power consumption (standby)	0.2 W
Power consumption (typical)	21.7 W
Power consumption (PowerSave)	19 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Cables included	AC, DisplayPort, USB
Package depth	690.12 mm
Package width	424.94 mm
Package height	169.93 mm
Package weight	9130 g
Harmonized System (HS) code	85285210

Weight and Dimensions

Bezel width (top)	7.4 mm
Depth (with stand)	185 mm
Width (with stand)	611.6 mm
Height (with stand)	525.3 mm
Weight (with stand)	6420 g
Bezel width (bottom)	21.1 mm
Depth (without stand)	43.6 mm
Height (without stand)	364.1 mm
Weight (without stand)	4570 g
