Dell P2720D User Manual

8 │ About your monitor
Product features
The Dell P2720D monitor has an active matrix, Thin-Film Transistor (TFT), Liquid
Crystal Display (LCD), anti-static, and LED backlight. The monitor features include:
∞
68.47 cm (27.0 in.) viewable area display (measured diagonally). 2560 x 1440
resolution, with full-screen support for lower resolutions.
∞ Wide viewing angle to allow viewing from a sitting or standing position, or while
moving from side-to-side.
∞ Color gamut of 99% sRGB.
∞ High Dynamic Contrast Ratio.
∞ Tilt, swivel, height, and rotate adjustment capabilities.
∞ Removable stand and Video Electronics Standards Association (VESA™) 100 mm
mounting holes for flexible mounting solutions.
∞ Digital connectivity with DisplayPort and HDMI.
∞ Equipped with 1 USB upstream port and 4 USB downstream ports.
∞ Plug and play capability if supported by your system.
∞ On-Screen Display (OSD) adjustments for ease of set-up and screen
optimization.
∞ Software and documentation media includes an Information File (INF), Image
Color Matching File (ICM), and product documentation.
∞ Security lock slot.
∞ Stand lock.
∞ Capability to switch from wide aspect to standard aspect ratio while maintaining
the image quality.
∞ 0.3 W standby power when in the sleep mode.
∞ Optimize eye comfort with a flicker-free screen.
WARNING: The possible long-term effects of blue light emission from
the monitor may cause damage to the eyes, including eye fatigue, digital
eye strain, and so on. ComfortView feature is designed to reduce the
amount of blue light emitted from the monitor to optimize eye comfort.

Dell P2720D Specifications

General

Doesn't contain	BRF, PVC
Sustainability certificates	RoHS, ENERGY STAR
Feet color	Black/Silver
Certification	TCO, NFPA 99
Product color	Black
Market positioning	Business
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 21 °
Panel mounting interface	100 x 100 mm
3D	No
Color gamut	99 %
Pixel pitch	0.233 x 0.233 mm
Screen shape	Flat
Pixel density	108 ppi
Response time	8 ms
Backlight type	LED
Display diagonal	27 \
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	49 - 75 Hz
Maximum refresh rate	60 Hz
Response time (fast)	5 ms
Horizontal scan range	29 - 113 kHz
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 1440p
Viewable size diagonal	684.7 mm
Viewable size, vertical	335.66 mm
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	596.74 mm
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1280 x 768 (WXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2048 x 1080, 2560 x 1440
HDMI version	1.4
USB hub version	2.0 / 3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
USB upstream port type	USB Type-B
Number of upstream ports	1
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	4
Current rating	1.6 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	55 W
Power consumption (standby)	0.2 W
Power consumption (typical)	21.7 W
Power consumption (PowerSave)	19 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Cables included	AC, DisplayPort, USB
Package depth	690.12 mm
Package width	424.94 mm
Package height	169.93 mm
Package weight	9130 g
Harmonized System (HS) code	85285210

Weight and Dimensions

Bezel width (top)	7.4 mm
Depth (with stand)	185 mm
Width (with stand)	611.6 mm
Height (with stand)	525.3 mm
Weight (with stand)	6420 g
Bezel width (bottom)	21.1 mm
Depth (without stand)	43.6 mm
Height (without stand)	364.1 mm
Weight (without stand)	4570 g
