Dell P2722H User Manual

62 | Operating the monitor
OSD warning messages
When the monitor does not support a particular resolution mode, you can see the
following message:
The current input timing is not supported by the monitor display.
Please change your input timing to 1920x1080, 60Hz or any other
monitor listed timing as per the monitor specications.
This means that the monitor cannot synchronize with the signal that it is receiving
from the computer. See Monitor Specifications for the Horizontal and Vertical
frequency ranges addressable by this monitor. Recommended mode is 1920 x 1080.
You can see the following message before the DDC/CI function is disabled:
The function of adjusting display setting using PC
application will be disabled.
Do you wish to disable DDC/CI function?
Yes
No
When the monitor enters the Standby mode, the following message will appear:
Going into Standby mode...
Activate the computer and wake up the monitor to gain access to the OSD.
If you press any button other than the power button, the following messages will
appear depending on the selected input:
No HDMI Signal form your device.
Press any key on the keyboard or move the mouse to wake it up.
If there is no display, press monitor joystick to open up the
Menu and select the correct input source.

Dell P2722H Specifications

General

HDMI version	1.4
Headphone out	No
USB hub version	2.0 / 3.2 Gen 1 (3.1 Gen 1)
Built-in USB hub	Yes
DisplayPort version	1.2
USB upstream port type	USB Type-B
Number of upstream ports	1
USB Type-A downstream ports quantity	4
Pivot angle	-90 - 90 °
LED indicators	Power
Tilt angle range	-5 - 21 °
Height adjustment	150 mm
Panel mounting interface	100 x 100 mm
Color depth	6 bit
Pixel pitch	0.2745 x 0.2745 mm
Screen shape	Flat
Pixel density	102 ppi
Response time	8 ms
Backlight type	LED
Display diagonal	27 \
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	50 - 76 Hz
Maximum refresh rate	60 Hz
Response time (fast)	5 ms
Horizontal scan range	30 - 83 kHz
Supported video modes	480p, 576p, 720p, 1080i, 1080p
Viewable size diagonal	686 mm
Viewable size, vertical	336.31 mm
sRGB coverage (typical)	99 %
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	68.6 cm
Viewable size, horizontal	597.89 mm
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
NVIDIA G-SYNC	-
AC input voltage	100 - 240 V
Power supply type	Internal
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	55 W
Power consumption (standby)	0.2 W
Power consumption (typical)	15 W
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Doesn't contain	PVC/BFR
Sustainability certificates	ENERGY STAR, EPEAT Gold, RoHS
Feet color	Silver
Product color	Black
Heavy metals free	Hg (mercury)
Market positioning	Business
Cables included	AC, DisplayPort, USB
Harmonized System (HS) code	85285210
Ethernet LAN (RJ-45) ports	0

Weight and Dimensions

Bezel width (top)	5.99 mm
Bezel width (side)	6.01 mm
Depth (with stand)	190.1 mm
Width (with stand)	609.9 mm
Height (with stand)	384.15 mm
Weight (with stand)	6770 g
Bezel width (bottom)	17.29 mm
Depth (without stand)	52.15 mm
Height (without stand)	359.6 mm
Weight (without stand)	4380 g
