Dell P2722H User Manual

8 | About your monitor
Product features
The Dell P2722H monitor has an active matrix, Thin-Film Transistor (TFT), Liquid
Crystal Display (LCD), and LED backlight. The monitor features include:
• CVAA compliant – Dell Technologies is committed to diversity and we are
continually improving the user experience for everyone. In our ongoing efforts
to strive for digital accessibility, this monitor meets Section 47 CFR 79.107 of the
21st Century Communications and Video Accessibility Act (CVAA). Select on-
screen text menus and commands, displayed via the On-Screen Menu function,
will be narrated using text-to-speech synthesis to aid accessibility of the visually
impaired. Read more about our commitment to enabling digital accessibility for
people with disabilities here.
• 68.60 cm (27 in.) active area display (Measured diagonally).
• 1920 x 1080 resolution, with full-screen support for lower resolutions.
• Color gamut of 99% sRGB.
• Digital connectivity with DisplayPort and HDMI.
• Equipped with 1 USB upstream port and 4 SuperSpeed USB 5 Gbps (USB3.2 Gen
1).
• Plug and play capability if supported by your computer.
• On-Screen Display (OSD) adjustments for ease of setup and screen optimization.
• Power and joystick buttons lock.
• Removable pedestal stand and Video Electronics Standards Association (VESA™)
100 mm mounting holes for flexible mounting solutions.
• Tilt, swivel, height, and rotate adjustment capabilities.
• Security lock slot.
• ≤0.3 W standby power when in Standby Mode.
• Supports Dell Display Manager.
• Optimize eye comfort with a flicker-free screen and low blue light feature.
• The Monitor use Low Blue Light panel and compliance with TUV Rheinland
(Hardware Solution) at factory reset/default setting model (Preset mode:
Standard).
WARNING: The possible long-term effects of blue light emission from the
monitor may cause damage to the eyes, including eye fatigue, digital eye
strain, and so on. ComfortView Plus feature is designed to reduce the
amount of blue light emitted from the monitor to optimize eye comfort.

Dell P2722H Specifications

General

HDMI version	1.4
Headphone out	No
USB hub version	2.0 / 3.2 Gen 1 (3.1 Gen 1)
Built-in USB hub	Yes
DisplayPort version	1.2
USB upstream port type	USB Type-B
Number of upstream ports	1
USB Type-A downstream ports quantity	4
Pivot angle	-90 - 90 °
LED indicators	Power
Tilt angle range	-5 - 21 °
Height adjustment	150 mm
Panel mounting interface	100 x 100 mm
Color depth	6 bit
Pixel pitch	0.2745 x 0.2745 mm
Screen shape	Flat
Pixel density	102 ppi
Response time	8 ms
Backlight type	LED
Display diagonal	27 \
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	50 - 76 Hz
Maximum refresh rate	60 Hz
Response time (fast)	5 ms
Horizontal scan range	30 - 83 kHz
Supported video modes	480p, 576p, 720p, 1080i, 1080p
Viewable size diagonal	686 mm
Viewable size, vertical	336.31 mm
sRGB coverage (typical)	99 %
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	68.6 cm
Viewable size, horizontal	597.89 mm
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
NVIDIA G-SYNC	-
AC input voltage	100 - 240 V
Power supply type	Internal
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	55 W
Power consumption (standby)	0.2 W
Power consumption (typical)	15 W
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Doesn't contain	PVC/BFR
Sustainability certificates	ENERGY STAR, EPEAT Gold, RoHS
Feet color	Silver
Product color	Black
Heavy metals free	Hg (mercury)
Market positioning	Business
Cables included	AC, DisplayPort, USB
Harmonized System (HS) code	85285210
Ethernet LAN (RJ-45) ports	0

Weight and Dimensions

Bezel width (top)	5.99 mm
Bezel width (side)	6.01 mm
Depth (with stand)	190.1 mm
Width (with stand)	609.9 mm
Height (with stand)	384.15 mm
Weight (with stand)	6770 g
Bezel width (bottom)	17.29 mm
Depth (without stand)	52.15 mm
Height (without stand)	359.6 mm
Weight (without stand)	4380 g
