Steps
1. Align the slot on the memory module with the notch on the memory module slot on the system board.
2. Slide the memory module into the slot on the system board.
3. Press down on the memory module to snap it into place.
4. Ensure that the securing clips have locked the memory module into place.
NOTE:
If the securing clips are not locking the memory module into place remove the memory module from the slot and
repeat steps 1 to 3.
5. Repeat the procedure above for the second memory module, if applicable.
Next steps
1. Install the base cover.
2. Follow the procedure in After working inside your computer.
Wireless card
Removing the wireless card
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
About this task
The following images indicate the location of the wireless card and provides a visual representation of the removal procedure.
22
Removing and installing components
