58 Dell EMC Networking with Isilon Front-End Deployment and Best Practices Guide | version 1.0
8 Validation
In addition to sending traffic between hosts, the configuration shown in both topologies can be validated with
the commands shown in this section. The validation for the layer 2 topology will only reference sections 8.1.3
– 8.1.9 for OS10EE and sections 8.2.3 – 8.2.8 for OS9.
Note: For more information on commands and output, see the Command Line Reference Guide for the
applicable switch (links to documentation are provided in Appendix B.
Command and output examples are provided for one spine and one leaf. The OS9 section will only cover the
validation of a single leaf as the spine layer is running OS10EE. Command output on other switches is similar.
8.1 OS10EE Validation commands
This section will cover the validation of the S4048-ON leaf switches that are running OS10EE as well the
Z9100-ON spine switches.
Command and output examples are provided for one spine and one leaf. Command output on other switches
is similar.
8.1.1 show ip bgp summary
When BGP is configured, this command shows the status of all BGP connections. Each spine has four
neighbors (the four leafs) and each leaf has two neighbors (the two spines).
Z9100-Spine1# show ip bgp summary
BGP router identifier 10.0.1.1 local AS number 64601
Neighbor AS MsgRcvd MsgSent Up/Down State/Pfx
192.168.1.1 64701 2119 2146 00:55:27 3
192.168.1.3 64702 2101 2113 00:54:38 3
192.168.1.5 64703 2291 2322 01:37:49 3
192.168.1.7 64704 2290 2310 01:37:36 3
S4048-Leaf1#show ip bgp summary
BGP router identifier 10.0.2.1 local AS number 64701
Neighbor AS MsgRcvd MsgSent Up/Down State/Pfx
192.168.1.0 64601 131660 131649 3d:21:49:06 10
192.168.2.0 64602 131685 131625 3d:21:49:04 10
8.1.2 show ip route bgp
On switches with BGP configured, this command is used to verify the BGP entries in the Routing Information
Base (RIB). Entries with multiple paths shown are used with ECMP. The two server networks in this example,
10.60.1.0 and 172.16.1.0, each have two paths from Z9100-Spine1, one through each leaf.
The first set of routes with a subnet mask of /32 are the IPs configured for router IDs.

Dell PowerEdge R730xd Specifications

General

Tcase	72.6 °C
Bus type	QPI
Stepping	R2
FSB Parity	No
Scalability	2S
Processor code	SR207
Processor cache	15 MB
Processor cores	6
Processor model	E5-2620V3
System bus rate	8 GT/s
Processor series	Intel Xeon E5-2600 v3
Processor socket	LGA 2011-v3
Processor threads	12
Processor codename	Haswell
Motherboard chipset	Intel C610
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	52.5 x 45 mm
Processor front side bus	- MHz
Processor boost frequency	3.2 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX
Thermal Design Power (TDP)	85 W
Number of processors installed	1
Maximum number of SMP processors	2
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR4-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	1600, 1866 MHz
Memory bandwidth supported by processor (max)	59 GB/s
Maximum internal memory supported by processor	768 GB
HDD size	3.5 \
HDD speed	7200 RPM
RAID levels	0, 1, 5, 6
HDD interface	Serial ATA, Serial Attached SCSI (SAS)
Total storage capacity	4000 GB
Maximum storage capacity	99.6 TB
Supported storage drive interfaces	Serial ATA
Memory slots	24
Internal memory	16 GB
Memory clock speed	2133 MHz
LAN controller	Broadcom 5720
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	4
Operating system installed	-
Compatible operating systems	Microsoft Windows Server 2008/2012 SP2, x86/x64 (x64 includes Hyper-VTM )\\r Microsoft Windows Server 2008/2012 R2, x64 (includes Hyper-VTM v2)\\r Microsoft Windows HPC Server 2008\\r Novell SUSE Linux Enterprise Server\\r Red Hat Enterprise Linux\\r VMware ESX
Chassis type	Rack (2U)
Power supply	750 W
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
Processor ARK ID	83352
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
PCI Express slots version	3.0
On-board graphics card model	Not available

Weight and Dimensions

Depth	684 mm
Width	440 mm
Height	87.3 mm
