Dell PowerEdge R730xd Deployment Guide

74 Dell EMC Networking with Isilon Front-End Deployment and Best Practices Guide | version 1.0
Note: Refer to Microsoft's DNS Resource Record Management for the specific steps in creating a DNS
server.
2. Navigate to Server Manager > Tools > DNS and configure the following:
DNS parameters
Parameter
Value
Forward Lookup Zone
dell.local
Reverse Lookup Zones
172.16.1, 172.16.2
Host A record for sczone1
sczonea, 172.16.1.249
Host A record for sczone2
sczoneb, 172.16.2.249
Delegation zone for sczone1
sczone1.dell.local, 172.16.1.249
Delegation zone for sczone2
sczone2.dell.local, 172.16.2.249
It is important that the DNS Host A record have a unique name that does not match the name that was
assigned to the SmartConnect zone within the OneFS file system. The Delegation zone, however, needs to
have a name that matches the SmartConnect zone. This will ensure that a connection to sczone1.dell.local
will reference the SmartConnect Zone 1 IP of 172.16.1.249. When this IP is referenced, it will round robin
through each node IP, assigning the workload to each node in turn, ensuring a balanced workload.
9.5 Validation
At this point in the configuration, the file system and the network can be validated. This can be accomplished
by selecting a server on one leaf pair and connecting to the file system assigned to the opposite subnet.

Dell PowerEdge R730xd Specifications

General

Tcase	72.6 °C
Bus type	QPI
Stepping	R2
FSB Parity	No
Scalability	2S
Processor code	SR207
Processor cache	15 MB
Processor cores	6
Processor model	E5-2620V3
System bus rate	8 GT/s
Processor series	Intel Xeon E5-2600 v3
Processor socket	LGA 2011-v3
Processor threads	12
Processor codename	Haswell
Motherboard chipset	Intel C610
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	52.5 x 45 mm
Processor front side bus	- MHz
Processor boost frequency	3.2 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX
Thermal Design Power (TDP)	85 W
Number of processors installed	1
Maximum number of SMP processors	2
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR4-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	1600, 1866 MHz
Memory bandwidth supported by processor (max)	59 GB/s
Maximum internal memory supported by processor	768 GB
HDD size	3.5 \
HDD speed	7200 RPM
RAID levels	0, 1, 5, 6
HDD interface	Serial ATA, Serial Attached SCSI (SAS)
Total storage capacity	4000 GB
Maximum storage capacity	99.6 TB
Supported storage drive interfaces	Serial ATA
Memory slots	24
Internal memory	16 GB
Memory clock speed	2133 MHz
LAN controller	Broadcom 5720
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	4
Operating system installed	-
Compatible operating systems	Microsoft Windows Server 2008/2012 SP2, x86/x64 (x64 includes Hyper-VTM )\\r Microsoft Windows Server 2008/2012 R2, x64 (includes Hyper-VTM v2)\\r Microsoft Windows HPC Server 2008\\r Novell SUSE Linux Enterprise Server\\r Red Hat Enterprise Linux\\r VMware ESX
Chassis type	Rack (2U)
Power supply	750 W
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
Processor ARK ID	83352
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
PCI Express slots version	3.0
On-board graphics card model	Not available

Weight and Dimensions

Depth	684 mm
Width	440 mm
Height	87.3 mm
