Dell PowerVault MD3200i Series User Manual

DELL PowerVault MD3200i/MD3220i Technical Guide Book
35
Environmental Specifications
Table 7. Environmental Specifications
Temperature
Operating 10° to 35°C (50° to 95°F) with a maximum temperature
gradation of 10°C per hour
Note: For altitudes above 2950 feet, the maximum operating
temperature is de-rated 1°F/550 ft.
Storage -40° to 65°C (-40° to 149°F) with a maximum temperature
gradation of 20°C per hour
Relative Humidity
Operating 20% to 80% (non-condensing) with a maximum humidity
gradation of 10% per hour
Storage 5% to 95% (non-condensing) with a maximum humidity gradation
of 10% per hour
Maximum Vibration
Operating 0.25 G at 3 – 200 Hz for 15 min
Storage 0.5 at 3 – 200 Hz for 15 min
Maximum Shock
Operating One shock pulse in the positive z axis (one pulse on each side of
the system) of 31 G for 2.6 ms in the operational orientation
Storage Six consecutively executed shock pulses in the positive and
negative x, y, and z axes (one pulse on each side of the system)
of 71 G for up to 2 ms
Altitude
Operating -16 to 3048 m (-50 to 10,000 ft)
Note: For altitudes above 2950 feet, the maximum operating
temperature is de-rated 1°F/550 ft.
Storage -16 to 10,600 m (-50 to 35,000 ft)
Airborne Contaminant Level
Class G2 or lower as defined by ISA-S71.04-1985

Dell PowerVault MD3200i Series Specifications

General

RAID Levels	0, 1, 5, 6, 10, 50, 60
Connectivity	iSCSI
Form Factor	2U rack-mountable
Drive Bays	12 x 3.5"
Max Capacity	Up to 192TB
Controller	Dual active controllers
Cache Memory	2GB per controller
Expansion	Supports up to 8 MD1200 expansion enclosures
Host Interface	1GbE iSCSI
Management	Modular Disk Storage Manager (MDSM)
Power Supply	Dual redundant 600W power supplies
Processor	Intel Xeon
Operating System Compatibility	Windows Server, Linux, VMware, Citrix XenServer
