Using Multimedia 67
1 Turn off the computer and the TV and/or audio device that you want to
connect.
2 Connect the composite video adapter to the S-video TV-out connector on
the computer.
3 Plug one end of the composite video cable into the composite video-input
connector on the composite video adapter.
4 Plug the other end of the composite video cable into the composite video-
input connector on the TV.
5 Plug one end of the S/PDIF digital audio cable into the S/PDIF audio
connector on the composite video adapter.
1 composite video adapter 2 composite video cable
3 standard audio cable
1 composite video adapter 2 composite video cable
1
2
3
2
1
