26  │  About your monitor

NOTE: Super speed USB 10 Gbps (USB 3.2 Gen2) functionality requires

a super speed USB 10 Gbps (USB 3.2 Gen2)-capable computer.

NOTE: The USB ports on the monitor work only when the monitor is

turned On or in Standby mode. If you turn Off the monitor and then

turn it On, the attached peripherals may take a few seconds to resume

normal functionality.

RJ45 Connector

Pin Signal

P1 MDI0+

P2 MDI0-

P3 MDI1+

P4 MDI1-

P5 CT

P6 CT

P7 MDI2+

P8 MDI2-

P9 MDI3+

P10 MDI3-
