Power-Button Board
Dell™Vostro™3300ServiceManual
Removing the Power-Button Board
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the battery.
3. Remove the base cover.
4. Remove the hard drive.
5. Remove the optical drive.
6. Remove the keyboard.
7. Remove the wireless local area network (WLAN) card.
8. Remove the wireless wide area network (WWAN) card.
9. Remove the palm rest.
10. Remove the screw that secures the power-button board to the palm rest.
11. Open the clip that secures the power-button cable to the power-button board and disconnect the cable from its connector on the system board.
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.

Dell Vostro 3300 Specifications

General

RAM	Up to 8 GB DDR3
Operating System	Windows 7 Professional
Optical Drive	DVD+/-RW
Bluetooth	Bluetooth 3.0
Processor	Intel Core i3
Display	13.3-inch HD (1366x768)
Storage	Up to 500GB HDD
Graphics	Intel HD Graphics
Wireless	802.11b/g/n
Ports	3 x USB 2.0, VGA, HDMI, Ethernet (RJ-45), Headphone/Microphone combo jack
Webcam	1.3MP
Battery	6-cell lithium-ion
