System Board
Dell™Vostro™3300ServiceManual
Removing the System Board
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the battery.
3. Remove the base cover.
4. Remove the hard drive.
5. Remove the optical drive.
6. Remove the WLAN card.
7. Remove the keyboard.
8. Remove the WWAN card.
9. Remove the memory.
10. Remove the palm rest.
11. Remove the screws that secure the system board to the computer.
12. Gently lift the system board up and away from the computer.
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
