Dell XPS 8950 User Manual

Processor
Removing the processor
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the left-side cover.
3. Remove the fan and heat-sink assembly (65 W) or the fan and heat-sink assembly (125 W), whichever applicable.
About this task
The following image(s) indicate the location of the processor and provides a visual representation of the removal procedure.
Steps
1. Press the release lever down and then push it away from the processor to release it from the securing tab.
2. Extend the release lever completely and open the processor cover.
CAUTION:
When removing the processor, do not touch any of the pins inside the socket or allow any objects
to fall on the pins in the socket.
3. Gently lift the processor from the processor socket.
Installing the processor
Prerequisites
If you are replacing a component, remove the existing component before performing the installation process.
About this task
The following image(s) indicate the location of the processor and provides a visual representation of the installation procedure.
50
Removing and installing components

Dell XPS 8950 Specifications

General

Processor	12th Gen Intel Core i5, i7, or i9
Operating System	Windows 11 Home or Pro
Chipset	Intel Z690
Memory	Up to 128GB DDR5
Storage	Up to 2TB SSD + 2TB HDD
Graphics	NVIDIA GeForce RTX 3060, RTX 3080 or AMD Radeon RX 6700 XT
Dimensions	173 mm
Ports (Front)	1x USB 3.2 Gen 1 Type-A, 1x USB 3.2 Gen 2 Type-C, Headphone/Mic
Ports (Rear)	Ethernet
Expansion Slots	1x PCIe x16, 1x PCIe x4, 1x PCIe x1
Power Supply	460W or 750W
Wireless	Bluetooth 5.2
Ports	USB 3.2 Gen 1 Type-A, USB 3.2 Gen 2x2 Type-C, USB 2.0, HDMI, DisplayPort, Ethernet
