Installation
Please note
Electrical connection
This oven is fitted with a plug and must be only
connected to a properly installed earthed
socket. In accordance with the appropriate
regulation, the socket must only be installed
and the connecting cable must only be
replaced by a qualified electrician. If the plug is
no longer accessible following installation and
all-pole isolating switch must be present on the
installation side with a contact gap of at least
3mm.
1. Select a level surface that provide enough
open space for the intake and / or outlet vents.
A minimum clearance of 3.0 inches (7.5cm) is
required between the oven and any adjacent
walls. One side must be open.
(1) Leave a minimum clearance of 12 inches
(30cm) above the oven.
(2) Do not remove the legs from the bottom of
the oven.
(3) Blocking the intake and/or outlet openings
can damage the oven.
(4) Place the oven as far away from radios and
TV as possible. Operation of microwave oven
may cause interference to your radio or TV
reception.
2. Plug your oven into a standard household
outlet. Besure the voltage and the frequency is
the same as the voltage and the frequency on
the rating label.
WARNING : Do not install oven over a range
cooktop or other heat-producing appliance. If
installed near or over a heat source, the oven
could be damaged and the warranty would be
void.
11
