99
max 290 mm
showing the
cooker when
installed
Area for GAS
and ELECTRIC
connection
GAS AND ELECTRIC CONNECTION
Figure 2
FITTING THE ADJUSTABLE FEET
The adjustable feet must be tted to the base of the cooker before use (gs. 3, 4).
Rest the rear of the cooker on a piece of the polystyrene packaging exposing the base for
the tting of the feet.
Fit the no. 4 (four) legs by screwing them tight into the support base as shown in gure 4.
LEVELLING THE COOKER
The cooker may be levelled by screwing the lower ends of the feet IN or OUT (g. 5).
Figure 4 Figure 5Figure 3
