Application Notes
Objects
The following is a list of predefined or “fixed” objects that reside in the Pulse Input Field
Module, which you cannot create or delete. When connected to a BACnet RS-485 MS/TP
network, these objects are readily accessible over the network. Connecting to a LINKnet
network is not an option.
Object
Name
Description
Default Value
DEV1
BACnet PI
Device Object
N/A
PI1
Pulse Input 1
Counts and Configures Pulses
N/A
PI2
Pulse Input 2
Counts and Configures Pulses
N/A
PI3
Pulse Input 3
Counts and Configures Pulses
N/A
PI4
Pulse Input 4
Counts and Configures Pulses
N/A
AV1
PI1 Converted Pulse Rate
Pulse Value (PI1 “Present”
Value)
N/A
AV2 PI1 Average Converted Pulse Rate Avg. Pulses (from PI Data tab) N/A
AV3 PI1 Sample Interval
Sample Interval (from PI Setup
tab)
60
AV4
PI1 Number of Sample Intervals
Number of Intervals (from PI
Adv.)
5
AV5 PI1 Total Pulses Total Pulses (from PI Data tab) N/A
AV6 PI2 Converted Pulse Rate
Pulse Value (PI2 “Present”
Value)
N/A
AV7
PI2 Average Converted Pulse Rate
Avg. Pulses (from PI Data tab)
N/A
AV8
PI2 Sample Interval
Sample Interval (from PI Setup
tab)
60
AV9
PI2 Number of Sample Intervals
Number of Intervals (from PI
Adv.)
5
AV10
PI2 Total Pulses
Total Pulses (from PI Data tab)
N/A
AV11
PI3 Converted Pulse Rate
Pulse Value (PI3 “Present”
Value)
N/A
AV12 PI3 Average Converted Pulse Rate Avg. Pulses (from PI Data tab) N/A
AV13 PI3 Sample Interval
Sample Interval (from PI Setup
tab)
60
AV14
PI3 Number of Sample Intervals
Number of Intervals (from PI
Adv.)
5
AV15 PI3 Total Pulses Total Pulses (from PI Data tab) N/A
AV16 PI4 Converted Pulse Rate
Pulse Value (PI4 “Present”
Value)
N/A
AV17
PI4 Average Converted Pulse Rate
Avg. Pulses (from PI Data tab)
N/A
AV18
PI4 Sample Interval
Sample Interval (from PI Setup
tab)
60
AV19 PI4 Number of Sample Intervals
Number of Intervals (from PI
Adv.)
5
