DVP-ES2/EX2/EC5/SS2/SA2/SX2/SE&TP Operation Manual - Programming
C-12
Special
D
Content
OFF

ON
STOP

RUN
RUN

STOP
Attrib.
Latch
-ed
Default
D1976*
↓
D1991*
The data which is written into slave ID#16 in the PLC LINK
0 - - R/W NO 0
D1994
Remaining times for PLC password setting on DVP-PCC01
0 - - R/W NO 0
D1995
Data length for PLC ID Setting on DVP-PCC01
0 - - R/W NO 0
D1996
1
st
Word of PLC ID Setting for DVP-PCC01 (Indicated by
Hex format corresponding to ASCII codes)
0 - - R/W NO 0
D1997
2
nd
Word of PLC ID Setting for DVP-PCC01 (Indicated by
Hex format corresponding to ASCII codes)
0 - - R/W NO 0
D1998
3
rd
Word of PLC ID Setting for DVP-PCC01 (Indicated by
Hex format corresponding to ASCII codes)
0 - - R/W NO 0
D1999
4
th
word of PLC ID Setting for DVP-PCC01 (Indicated by
Hex format corresponding to ASCII codes)
0 - - R/W NO 0
D4000
↓
D4999
Present value of an object in the TP program
D4000: Present value of object 1
D4001: Present value of object 2
…
D4999: Present value of object 999
- - - R/W NO 0
C.2.1 PLC CPU Built-in Inputs and Outputs
 Analog inputs
Model
Type
22XA1R/T 21EX1R/T
Voltage
-10V ~ +10V
-2000 ~ +2000
N/A
Current
-20mA ~ +20mA
-1000 ~ +1000
N/A
+4mA ~ +20mA
+0 ~ +1000
+0 ~ +4000
0~20mA
N/A
+0 ~ +4000
Temperature
Pt100
-20℃~300℃
N/A -200 ~ +3000
 Analog outputs
Model
Type
22XA1R/T 21EX1R/T
Voltage
-10V ~ +10V
-2000 ~ +2000
N/A
Current
+0mA ~ +20mA
+0 ~ +4000
+0 ~ +4000
+4mA ~ +20mA
+0 ~ +4000
+0 ~ +4000
