Delta DVP-ES2 User Manual

Appendix C Inforamation about TP Series Text Panels
C-25
C.4 Instructions applicable to TP
The instructions which are applicable to TP are listed below. Please refer to chapter 3 for more
information about the instructions.
C.4.1 Basic Instructions
Instruction
Function
LD
Load NO contact
LDI
Load NC contact
AND
Connect NO contact in series
ANI
Connect NC contact in series
OR
Connect NO contact in parallel
ORI
Connect NC contact in parallel
ANB
Connect a block in series
ORB
Connect a block in parallel
MPS
Start of branches. Stores current result of program evaluation
MRD
Reads the stored current result from previous MPS
MPP
End of branches. Pops (reads and resets) the stored result in previous
MPS
OUT
Output coil
SET
Latches the ON status
RST
Resets contacts, registers or coils
MC
Master control Start
MCR
Master control Reset
END
Program End
NOP
No operation
P
Pointer
I
Interrupt program pointer
STL
Step ladder start instruction
RET Step ladder return instruction
NP
Negative contact to Positive contact
PN
Positive contact to Negative contact
C.4.2 Numerical List of Instructions
Classification API
Mnemonic
PULSE
Function
16 bits
32 bits
Loop Control
00
CJ
–

Conditional jump
01
CALL
–

Call subroutine
02
SRET
–
–
Subroutine return
03
IRET
–
–
Interrupt return
04
EI
–
–
Enable interrupt
05
DI
–
–
Disable interrupt
06
FEND
–
–
The end of the main program (First end)
07
WDT
–

Watchdog timer refresh
08
FOR
–
–
Start of a For-Next Loop
09
NEXT
–
–
End of a For-Next Loop
Transmission
Comparison
10
CMP
DCMP

Compare
11
ZCP
DZCP

Zone compare
12
MOV
DMOV

Move
13
SMOV
–

Shift move
