Delta M Series User Manual

13
2.7 Equipment overview
Figure7:M10-TL-USe󰀩ciencyplot
Boost MOS
Boost Inductor
Inverter MOS
Inverter Inductor
ST 88N65M5
U-Flux uH
STY145N65M5
U-Flux uH
Load 10% 20% 30% 50% 75% 100% CEC
Pout(W) 960 1924.7 2880 4807 7204 9600
Uin(V) 300.33 300.16 300.07 299.89 300.68 300.45
EFF(%) 95.46 97.04 97.54 97.77 97.61 97.26
DP(W) 45.6 58.8 72.7 109.5 176.1 270.2
Cofficient
4% 5% 12% 21% 53% 5%
Load 10% 20% 30% 50% 75% 100% CEC
Pout(W) 962.8 1924.5 2881.6 4800 7206 5762
Uin(V) 380.68 380.64 380.55 380.42 380.27 376.40
EFF(%) 96.36 97.61 98.01 98.08 97.83 97.72
DP(W) 36.4 47.1 58.9 94.2 159.9 134.6
Cofficient
4% 5% 12% 21% 53% 5%
Load 10% 20% 30% 50% 75% 100% CEC
Pout(W) 961.2 1919.6 2876.1 4805.3 7208 9602
Uin(V) 480.04 480.00 479.97 479.87 479.64 480.79
EFF(%) 95.13 96.87 97.50 97.81 97.65 97.36
DP(W) 49.3 62.0 73.7 107.7 173.4 260.2
Cofficient
4% 5% 12% 21% 53% 5%
Manufacturer: Delta Electronics (Shanghai) Co., Ltd. HangZhou Branch
Model #: Delta 10kW TL
Rated Maximum Continuous Output Power: 9.60 kW Night Tare Loss: W
Vmin: 300 Vdc Vnom: 380 Vdc Vmax: 480 Vdc
Power Level (%; kW)
10% 20% 30% 50% 75% 100%
Input Voltage (Vdc) 0.05 0.10 0.15 0.25 0.38 0.50 Wtd
Vmin 300
95.46 97.04 97.54 97.77 97.61 97.26 97.5
Vnom 380
96.36 97.61 98.01 98.08 97.83 97.50 97.8
Vmax 480
95.13 96.87 97.50 97.81 97.65 97.36 97.5
CEC Efficiency = 97.5%
300 Vdc
380 Vdc
480 Vdc
测试条件
97.50
97.83
97.51
70
75
80
85
90
95
100
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
Efficiency, %
% of Rated Output Power
300 Vdc
380 Vdc
480 Vdc
(1) Inverter Power Box
(2) Wiring Box Cover
(3) LED Lights
(4) Mounting Plate
(5) Wiring Box
(6) Conduit Plugs
Figure 8: Exterior view of solar inverter main
components
(1)
(3)
(4)
(5)
(2)
(6)
