逆变器外部组件如图2-4所示。详细的输出与输入接口请参考图 2-5。
图2-4 : 外观介绍
2.4 外观介绍
图2-5 : 输出入接口介绍
AC Connector
380/400Vac, 3Ph
Fan *5Manual
Switch
String1
String2
String3
Communication
-RS-485 *2
-EPO *1
-Dry Contact *2
-Digital Input*6
DC1 DC2
String10
String11
String12
String4
String5
String6
String7
String8
String9
Display
Air inlet
Label
Input/
Output
Interfaces
SUB-1G
(optional)
86
产品概观
