Chapter 4 Parameters  VFD-EL-W
4-83
Content Address Function
16: Auto-acceleration/deceleration failure (cFA)
17: Software and parameter password protection enabled (codE)
18: Power Board CPU WRITE failure (cF1.0)
19: Power Board CPU READ failure (cF2.0)
20: CC, OC Hardware protection failure (HPF1)
21: OV Hardware protection failure (HPF2)
22: Reserved
23: OC Hardware protection failure (HPF4)
24: U-phase error (cF3.0)
25: V-phase error (cF3.1)
26: W-phase error (cF3.2)
27: DC bus error (cF3.3)
28: IGBT Overheat error (cF3.4)
29: Reserved
30: Reserved
31: Reserved
32: Reserved
33: Reserved
34: Reserved
35: Reserved
36: Reserved
37: OPHL
2101H
Status of the AC motor drive
bit 0–1
00B: RUN LED is off, STOP LED is on (the AC motor
drive stops).
01B: RUN LED blinks, STOP LED is on (when the AC
motor drive decelerates to stop).
10B: RUN LED is on, STOP LED blinks (when the AC
motor drive is in standby).
11B: RUN LED is on, STOP LED is off (when the AC
motor drive runs).
bit 2 1: JOG command
bit 3–4
00B: FWD LED is on, REV LED is off (when the AC
motor drive runs forward).
01B: FWD LED is on, REV LED blinks (when the AC
motor drive runs from reverse to forward).
10B: FWD LED blinks, REV LED is on (when the AC
motor drive runs from forward to reverse).
11B: FWD LED is off, REV LED is on (when the AC
motor drive runs in reverse).
bit 5–7
Reserved
bit 8
1: Master frequency is controlled by the communication
interface.
bit 9 1: Master frequency is controlled by the analog signal.
