Chapter 2 InstallationC2000 Plus
2-5
2-2 Airflow and Power Dissipation
Model No.
Airflow Rate for Cooling
Power Dissipation for
AC Motor Drive
Flow Rate (Unit: cfm) Flow Rate (Unit: m
3
/ hr) Power Dissipation (Unit: watt)
External Internal Total External Internal Total
Loss External
(Heat sink)
Internal Total
VFD007C23A-21 - - - - - - 33 27 61
VFD015C23A-21 14 - 14 24 - 24 56 31 88
VFD022C23A-21 14 - 14 24 - 24 79 36 115
VFD037C23A-21 10 - 10 17 - 17 113 46 159
VFD055C23A-21 40 14 54 68 24 92 197 67 264
VFD075C23A-21 66 14 80 112 24 136 249 86 335
VFD110C23A-21 58 14 73 99 24 124 409 121 529
VFD150C23A-21 166 12 178 282 20 302 455 161 616
VFD185C23A-21 166 12 178 282 20 302 549 184 733
VFD220C23A-21 166 12 178 282 20 302 649 216 865
VFD300C23A-00
VFD300C23A-21
179 30 209 304 51 355 913 186 1099
VFD370C23A-00
VFD370C23A-21
179 30 209 304 51 355 1091 220 1311
VFD450C23A-00
VFD450C23A-21
228 73 301 387 124 511 1251 267 1518
VFD550C23A-00
VFD550C23A-21
228 73 301 387 124 511 1401 308 1709
VFD750C23A-00
VFD750C23A-21
246 73 319 418 124 542 1770 369 2139
VFD900C23A-00
VFD900C23A-21
224 112 336 381 190 571 2304 484 2788
VFD007C43A-21
VFD007C4EA-21
- - - - - - 33 25 59
VFD015C43A-21
VFD015C4EA-21
- - - - - - 45 29 74
VFD022C43A-21
VFD022C4EA-21
14 - 14 24 - 24 71 33 104
VFD037C43A-21
VFD037C4EA-21
10 - 10 17 - 17 103 38 141
VFD040C43A-21
VFD040C4EA-21
10 - 10 17 - 17 116 42 158
VFD055C43A-21
VFD055C4EA-21
10 - 10 17 - 17 134 46 180
VFD075C43A-21
VFD075C4EA-21
40 14 54 68 24 92 216 76 292
VFD110C43A-21
VFD110C4EA-21
66 14 80 112 24 136 287 93 380
VFD150C43A-21
VFD150C4EA-21
58 14 73 99 24 124 396 122 518
VFD185C43A-21
VFD185C4EA-21
99 21 120 168 36 204 369 138 507
VFD220C43A-21
VFD220C4EA-21
99 21 120 168 36 204 476 158 635
VFD300C43A-21
VFD300C4EA-21
126 21 147 214 36 250 655 211 866
VFD370C43S-00
VFD370C43S-21
179 30 209 304 51 355 809 184 993
VFD450C43S-00
VFD450C43S-21
179 30 209 304 51 355 929 218 1147
VFD550C43A-00
VFD550C43A-21
179 30 209 304 51 355 1156 257 1413
VFD750C43A-00
VFD750C43A-21
186 30 216 316 51 367 1408 334 1742
To Next Page
