Denon AVR-1404 Service Manual

3
3AVR-1404/484
DISASSEMBLY
(Follow the procedure below in reverse order when reassembling.)
1. Top Cover
(1) Remove 6 screws ① and 3 screws ② , detach the Top cover in the arrow direction.
2. Front Panel
(1) Remove 4 screws ③ and 2 screws ④ .
(2) Detach the Front Panel in the arrow direction.
3. Rear Panel
(1) Remove cord bushing ⑤ from the Rear Panel.
(2) Remove 30 screws ⑥ .
(3) Detach the Rear Panel in the arrow direction.
Top Cover
1
2
1
Front Panel
4
3
5
Rear Panel
6
6

Denon AVR-1404 Specifications

General

Brand	Denon
Model	AVR-1404
Category	Stereo Receiver
Language	English
