Denon AVR-1404 Service Manual

47
47AVR-1404/484
PARTS LIST OF EXPLODED VIEW
Note: The symbols in the column "Remarks" indicate the following destinations.
E3: U.S.A. & Canada model EU: U.S.A. model (AVR-484) E2: Europe model
E2A: Asia model E1C: China model EUT: Taiwan R.O.C. model
E1K: Korea model
Ref. No. Part No. Part Name Remarks Q'ty New
44A 963 0108 001 Main P.W.B. Ass'y for E3,EU 1 *
44A 963 0108 014 Main P.W.B. Ass'y for E2 1 *
44A 963 0108 027 Main P.W.B. Ass'y for E2A 1 *
44A 963 0108 030 Main P.W.B. Ass'y for E1C 1 *
44A 963 0108 043 Main P.W.B. Ass'y for EUT 1 *
44A 963 0108 056 Main P.W.B. Ass'y for E1K 1 *
44 - Main P.W.B.
48 - Input P.W.B.
53 - Front CNT P.W.B.
51A 963 0108 108 Pre-amp P.W.B. Ass'y 1 *
51 - Pre-amp P.W.B.
42A 963 0108 205 CNT P.W.B. Ass'y for E3,EU 1 *
42A 963 0108 218 CNT P.W.B. Ass'y for E2,E2A 1 *
42A 963 0108 221 CNT P.W.B. Ass'y for E1C,EUT 1 *
42A 963 0108 234 CNT P.W.B. Ass'y for E1K 1 *
42 - Encoder P.W.B.
43 - Headphone P.W.B.
45 - CNT P.W.B.
47 - Tuner P.W.B.
50 - C-Video P.W.B.
52 - S-Video P.W.B.
65 - Outlet P.W.B. for E1K
66 - Power SW P.W.B. for E2,E2A,E1C,EUT,E1K
41A 963 0108 302 CPU P.W.B. Ass'y for E3,EU 1 *
41A 963 0108 315 CPU P.W.B. Ass'y for E2,E2A 1 *
41A 963 0108 328 CPU P.W.B. Ass'y for E1C,EUT,E1K 1 *
41 - Front P.W.B.
46 - Video CNT P.W.B.
65 - Outlet P.W.B. for E2,E2A
70 - CPU P.W.B.
49A 963 0108 409 DSP P.W.B. Ass'y 1 *
49 - DSP P.W.B.
1 963 0108 506 Front panel for E3 1 *
1 963 0108 519 Front panel for EU 1 *
1 963 0108 522 Front panel for E2 1 *
1 963 0108 535 Front panel for E2A 1 *
1 963 0108 548 Front panel for E1C,EUT,E1K 1 *
2 963 0051 501 DENON badge for black model 1
2 963 0051 527 DENON badge for silver model 1 *
2 963 0051 514 DENON badge for gold model 1
3 963 0093 116 Display window for E3,EU,E1C,EUT,E1K 1
3 963 0093 129 Display window for E2,E2A 1
4 963 0108 603 Volume knob for black model 1 *
4 963 0108 629 Volume knob for silver model 1 *
4 963 0108 616 Volume knob for gold model 1 *
5 963 0108 700 Function knob for black model 1 *
5 963 0108 726 Function knob for silver model 1 *
5 963 0108 713 Function knob for gold model 1 *
6 963 0108 807 Select knob for black model 1 *
6 963 0108 810 Select knob for silver model 1 *
6 963 0093 420 Select knob for gold model 1
