AVR-1907 / AVR-787 / AVC-1630
M30624FGPFP Terminal Function
No. Pin Name I/O/T Interrupt Pin Function
1 P9_6 O SW_SUM
2 P9_5 I I-POD DET
3 P9_4 O BU2090_Clock
4 P9_3 O BU2090_Data_1/LC74781_Data
5 P9_2 O BU2090_Data_2/LC74781_Clock
6 P9_1(TB1IN) I INT REMOCON
7 P9_0 I AD1328_SDIN
8 BYTE I BYTE
9 CNVSS(UP_GRADE) I CNVSS
10 P8_7 O BU4094_Data
11 P8_6 O FLD_RESET_BU4094_ENABLE
12 RESET I RESET
13 XOUT O XOUT
14 VSS I VSS
15 XIN I XIN
16 VCC1 I VCC1(+5V)
17 P8_5 I NMI
18 P8_4(INT2) I INT FLAG0
19 P8_3(INT1) I INT LC89057_INT
20 P8_2(INT0) I INT PROTECTION
21 P8_1 O FLD_CLK
22 P8_0 O FLD_DATA
23 P7_7 O FLD_CE
24 P7_6 O NC
25 P7_5 I/O ADV7180/7172_DATA
26 P7_4 O GREEN_LED
27 P7_3 I/O ADV7180/7172_CLK
28 P7_2 O NC
29 P7_1(RXD) I INT I-POD RX
30 P7_0(TXD) O INT I-POD TX
31 P6_7(UP_GRADE) O NC
32 P6_6(UP_GRADE) O NC
33 P6_5 I PLL_IF_COUNT
34 P6_4 O PLL_DATA OUT/XM_DAC_DATA
35 P6_3 O INT XM_UART_TX
36 P6_2 I INT XM_UART_RX
37 P6_1 O PLL_CLK/XM_DAC_CLK/BU4094_CLK
38 P6_0 O PLL_CE
39 P5_7 I TUNED
40 P5_6 I STEREO
41 P5_5(UP_GRADE) O NC
42 P5_4 I VOL_ENCODER_UP
43 P5_3 I VOL_ENCODER_DOWN
44 P5_2 I SEL_UP
45 P5_1 I SEL_DOWN
46 P5_0(UP_GRADE) O NC
47 P4-7 O NC
48 P4-6 I RDS_DATA
49 P4-5 O ERR_MUTE
50 P4-4 O BSE
51 P4_3 I LC89057_EMPHASIS
52 P4_2 I SHARC_SDIN
53 P4_1 I LC89057W_SDIN
54 P4_0 O EEPROM_RESET
55 P3_7 O LC89057W_RESET
