46
AVR-1907 / AVR-787 / AVC-1630
PARTS LIST OF P.W.B. UNIT
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
＊"nsp" 印の部品は常時在庫していませんので供給に長時間を要することがあります。場合によっては、供給をお断りする場合があります。
＊ Part indicated with the mark “nsp” are not always in stock and possibly to take a long period of time for supplying, or in some case supplying of part may be refused.
Note: The symbols in the column "Remarks" indicate the following destinations.
1907E3 : U.S.A. & Canada model (AVR-1907) 787E3 : U.S.A. & Canada model (AVR-787)
E2 : Europe model E2A : Asia model EUT : Taiwan R.O.C. model
E1K : Korea model JP : Japan model(AVC-1630)
MAIN P.W.B. UNIT ASSY
Ref. No. nsp Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC101 00D 963 0219 408 IC CJ7815 J126781500090S
IC102 00D 963 0219 505 IC CJ7915F J126791500070S
IC103 00D 963 0057 806 IC KIA78R05PI J126780500370S
IC104 00D 963 0219 204 IC CJ7805 J126780500430S
! IC105,106 00D 960 0195 808 IC ICP-N15 J120001500030S
Q104C 00D 960 0196 506 TR KSC1845F J5021845F0000S
Q104FL 00D 960 0196 506 TR KSC1845F J5021845F0000S
Q104FR 00D 960 0196 506 TR KSC1845F J5021845F0000S
Q104SL 00D 960 0196 506 TR KSC1845F J5021845F0000S
Q104SR 00D 960 0196 506 TR KSC1845F J5021845F0000S
Q111-115 00D 963 0121 208 TR KRC107M J6020107M0010S
Q116 00D 960 0196 409 TR 2SC1740SR J5021740S0010S
Q117,118 00D 963 0121 208 TR KRC107M J6020107M0010S
Q151 00D 960 0196 409 TR 2SC1740SR J5021740S0010S
Q171 00D 960 0196 700 TR KTC3200BL J5023200B0050S
Q171A 00D 960 0196 302 TR KTA1268BL J5001268B0050S
Q171B 00D 960 0196 302 TR KTA1268BL J5001268B0050S
Q171C 00D 960 0196 302 TR KTA1268BL J5001268B0050S
Q171D 00D 960 0196 302 TR KTA1268BL J5001268B0050S
Q172-177 00D 960 0196 700 TR KTC3200BL J5023200B0050S
Q178 00D 960 0196 302 TR KTA1268BL J5001268B0050S
Q179 00D 963 0226 705 TR KTC1027Y J5021027Y0020S
Q180,181 00D 960 0196 302 TR KTA1268BL J5001268B0050S
Q182,183 00D 960 0196 700 TR KTC3200BL J5023200B0050S
D101 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D101C 00D 963 0219 709 D,SWITCHING 1N4148W K005041480020S
D101FL 00D 963 0219 709 D,SWITCHING 1N4148W K005041480020S
D101FR 00D 963 0219 709 D,SWITCHING 1N4148W K005041480020S
D101SL 00D 963 0219 709 D,SWITCHING 1N4148W K005041480020S
D101SR 00D 963 0219 709 D,SWITCHING 1N4148W K005041480020S
D102 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D102C 00D 963 0219 709 D,SWITCHING 1N4148W K005041480020S
D102FL 00D 963 0219 709 D,SWITCHING 1N4148W K005041480020S
D102FR 00D 963 0219 709 D,SWITCHING 1N4148W K005041480020S
D102SL 00D 963 0219 709 D,SWITCHING 1N4148W K005041480020S
D102SR 00D 963 0219 709 D,SWITCHING 1N4148W K005041480020S
D103-105 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D121-127 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D131A 00D 960 0197 107
D,RECTIFIER BRIDGE KBPC604
K047604000020S
D131B 00D 960 0197 107
D,RECTIFIER BRIDGE KBPC604
K047604000020S
D132 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D135 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D137 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D138A 00D 963 0058 407 D,SWITCHING IN4007 K000400700520S
D141-146 00D 963 0058 407 D,SWITCHING IN4007 K000400700520S
D148 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D149,150 00D 963 0058 407 D,SWITCHING IN4007 K000400700520S
D151 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D152,153 00D 963 0058 407 D,SWITCHING IN4007 K000400700520S
D158-160 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D900-903 00D 963 0219 709 D,SWITCHING 1N4148W K005041480020S
ZD101C 00D 963 0279 804 D,ZENER 0.2W 4.3V UDZ K06604R34P410S
