Denon AVR-1905 User Manual

12
SURROUND
Before playing with the surround function
• Before playing with the surround function, be sure to use the test tones to adjust the playback level from the different speakers. This adjustment
can be performed with the system setup (see page 19) or from the remote control unit, as described below.
• Adjusting with the remote control unit using the test tones is only possible in the “Auto” mode and only effective in the STANDARD
(DOLBY/DTS SURROUND) modes. The adjusted levels for the different modes are automatically stored in the memory.
1
Set the STANDARD (DOLBY/DTS SURROUND) modes.
2
Press the TEST TONE button.
STANDARD
(Main unit) (Remote control unit)
(Remote control unit)
1
3
2, 4
3
1
3
Test tones are output from the
different speakers. Use the channel
volume adjust buttons to adjust so
that the volume of the test tones is
the same for all the speakers.
(Remote control unit)
4
After completing the adjustment, press
the TEST TONE button again.
(Remote control unit)
45
ENGLISH

Denon AVR-1905 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	80 W
Product color	Black
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital EX, Dolby Pro Logic IIx
Digital Signal Processing (DSP)	Yes
HDMI in	0
Composite video in	4
Digital audio coaxial in	1
Component video (YPbPr/YCbCr) in	3
S-Video outputs quantity	2
Ethernet LAN	No
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
AC input voltage	120 V
AC input frequency	60 Hz

Weight and Dimensions

Depth	171 mm
Width	434 mm
Height	416 mm
Weight	11900 g
