AVR-2105/885 / AVC-1890
PARTS LIST OF EXPLODED VIEW (FOR U.S.A. & CANADA)
Ref. No. Part No. Part Name Remarks Q'ty New
00D 963 0155 009 MAIN P.W.B ASSY 1 *
12 SWITCH P.W.B ASSY
13 POWER SWITCH P.W.B ASSY
15 HEAD PHONE P.W.B ASSY
44 VIDEO CNT P.W.B ASSY
39 MAIN P.W.B ASSY
00D 963 0155 106 CPU,FRONT P.W.B ASSY 1 *
17 FRONT S-VIDEO P.W.B ASSY
18 V.AUX P.W.B ASSY
19 FRONT OPTICAL P.W.B ASSY
35 CDR-CNT P.W.B ASSY
21 FRONT P.W.B ASSY
31 CPU P.W.B ASSY
00D 963 0155 203 CNT,PRE-AMP P.W.B ASSY 1 *
32 EXT-INPUT P.W.B ASSY
43 VIDEO-PREOUT-CNT P.W.B ASSY
45 OUTLET P.W.B ASSY
54 2CH-AMP P.W.B ASSY
30 CNT P.W.B ASSY
40 PRE-AMP P.W.B ASSY
00D 963 0155 300 INPUT,VIDEO P.W.B ASSY 1 *
20 MIC P.W.B ASSY
37 VIDEO P.W.B ASSY
41 COMPONENT P.W.B ASSY
42 PRE-OUT P.W.B ASSY
34 INPUT P.W.B ASSY
00D 963 0155 407 DSP P.W.B ASSY 1 *
36 DSP P.W.B ASSY
1 00D 963 0152 109 WINDOW 1
2 00D 963 0152 303 INPUT KNOB AVR-2105 1
2 00D 963 0152 400 INPUT KNOB AVA-885 1
3 00D 963 0051 501 DENON BADGE AVR-2105 1
3 00D 963 0051 527 DENON BADGE AVA-885 1
4 00D 963 0051 310 LED LENS 2
5 00D 963 0152 604 VOLUME KNOB AVR-2105 1
5 00D 963 0152 701 VOLUME KNOB AVA-885 1
6 00D 963 0152 905 SELECT KNOB AVR-2105 1
6 00D 963 0153 001 SELECT KNOB AVA-885 1
7 00D 963 0149 808 FRONT PANEL AVR-2105 1
7 00D 963 0149 905 FRONT PANEL AVA-885 1
8 00D 963 0151 809 RCA COVER AVR-2105 1
8 00D 963 0151 906 RCA COVER AVA-885 1
9 00D 963 0151 207 FRONT FRAME AVR-2105 1
9 00D 963 0151 702 FRONT FRAME AVA-885 1
10 00D 963 0137 807 STANDBY LENS 1
11 00D 963 0140 001 STANDBY BUTTON AVR-2105 1
11 00D 963 0140 108 STANDBY BUTTON AVA-885 1
14 00D 963 0139 708 POWER BUTTON AVR-2105 1
14 00D 963 0139 805 POWER BUTTON AVA-885 1
16 00D 963 0094 801 3KEY(A) BUTTON 4
22 00D 963 0137 205 CHASSIS 1
23 00D 963 0137 904 FOOT 4
24 00D 963 0051 103 CARD SPACER 2
25 00D 960 0003 301 PWB SUPPORTER 2
26 00D 960 0184 107 SUPPORTER BRACKET 1
27 00D 963 0044 602 P.C.SUPPORTER 2
28 00D 963 0092 609 TRANS BRACKET 1
