AVR-2105/885 / AVC-1890
PARTS LIST OF EXPLODED VIEW (FOR EUROPE, ASIA & KOREA)
Ref. No. Part No. Part Name Remarks Q'ty New
00D 963 0155 504 MAIN P.W.B ASSY Europe, Asia 1 *
00D9630156406 MAIN P.W.B ASSY Korea 1 *
12 SWITCH P.W.B ASSY
13 POWER SWITCH P.W.B ASSY
15 HEAD PHONE P.W.B ASSY
44 VIDEO CNT P.W.B ASSY
39 MAIN P.W.B ASSY
00D 963 0155 805 CPU,FRONT P.W.B ASSY Europe, Asia 1 *
00D 963 0156 804 CPU,FRONT P.W.B ASSY Korea 1 *
17 FRONT S-VIDEO P.W.B ASSY
18 V.AUX P.W.B ASSY
19 FRONT OPTICAL P.W.B ASSY
35 CDR-CNT P.W.B ASSY
21 FRONT P.W.B ASSY
31 CPU P.W.B ASSY
00D 963 0155 601 CNT,PRE-AMP P.W.B ASSY Europe, Asia 1 *
00D 963 0156 503 CNT,PRE-AMP P.W.B ASSY Korea 1 *
32 EXT-INPUT P.W.B ASSY
43 VIDEO-PREOUT-CNT P.W.B ASSY
45 OUTLET P.W.B ASSY
54 2CH-AMP P.W.B ASSY
30 CNT P.W.B ASSY
40 PRE-AMP P.W.B ASSY
00D 963 0156 008 INPUT,VIDEO P.W.B ASSY Europe, Asia 1 *
00D 96 30156 600 INPUT,VIDEO P.W.B ASSY Korea 1 *
20 MIC P.W.B ASSY
37 VIDEO P.W.B ASSY
41 COMPONENT P.W.B ASSY
42 PRE-OUT P.W.B ASSY
34 INPUT P.W.B ASSY
00D 963 0155 407 DSP P.W.B ASSY 1 *
36 DSP P.W.B ASSY
1 00D 963 0149 604 WINDOW Europe, Asia 1
1 00D 963 0138 204 WINDOW Korea 1
2 00D 963 0152 303 INPUT KNOB Black model 1
2 00D 963 0152 400 INPUT KNOB Silver model 1
2 00D 963 0152 507 INPUT KNOB Gold model 1
3 00D 963 0051 501 DENON BADGE Black model 1
3 00D 963 0051 527 DENON BADGE Silver model 1
3 00D 963 0051 514 DENON BADGE Gold model 1
4 00D 963 0051 310 LED LENS 2
5 00D 963 0152 604 VOLUME KNOB Black model 1
5 00D 963 0152 701 VOLUME KNOB Silver model 1
5 00D 963 0152 808 VOLUME KNOB Gold model 1
6 00D 963 0152 905 SELECT KNOB Black model 1
6 00D 963 0153 001 SELECT KNOB Silver model 1
6 00D 963 0153 108 SELECT KNOB Gold model 1
7 00D 963 0150 004 FRONT PANEL Black model 1
7 00D 963 0150 101 FRONT PANEL Silver model 1
7 00D 963 0150 208 FRONT PANEL Gold model 1
8 00D 963 0151 809 RCA COVER Europe (Black model) 1
8 00D 963 0151 906 RCA COVER Europe (Silver model) 1
8 00D 963 0152 002 RCA COVER Asia 1
9 00D 963 0151 304 FRONT FRAME Black model 1
9 00D 963 0151 605 FRONT FRAME Silver model 1
9 00D 963 0151 401 FRONT FRAME Gold model 1
10 00D 963 0137 807 STANDBY LENS 1
