AVR-2105/885 / AVC-1890
PARTS LIST OF EXPLODED VIEW (FOR U.K. & CHINA)
Ref. No. Part No. Part Name Remarks Q'ty New
00D 963 0155 708 MAIN P.W.B ASSY U.K. 1 *
00D 963 0156 707 MAIN P.W.B ASSY China 1 *
12 SWITCH P.W.B ASSY
13 POWER SWITCH P.W.B ASSY
15 HEAD PHONE P.W.B ASSY
44 VIDEO CNT P.W.B ASSY
39 MAIN P.W.B ASSY
00D 963 0155 805 CPU,FRONT P.W.B ASSY U.K. 1 *
00D 963 0156 804 CPU,FRONT P.W.B ASSY China 1 *
17 FRONT S-VIDEO P.W.B ASSY
18 V.AUX P.W.B ASSY
19 FRONT OPTICAL P.W.B ASSY
35 CDR-CNT P.W.B ASSY
21 FRONT P.W.B ASSY
31 CPU P.W.B ASSY
00D 963 0155 902 CNT,PRE-AMP P.W.B ASSY 1 *
32 EXT-INPUT P.W.B ASSY
43 VIDEO-PREOUT-CNT P.W.B ASSY
54 2CH-AMP P.W.B ASSY
30 CNT P.W.B ASSY
40 PRE-AMP P.W.B ASSY
00D 963 0156 008 INPUT,VIDEO P.W.B ASSY U.K. 1 *
00D 963 0156 901 INPUT,VIDEO P.W.B ASSY China 1 *
20 MIC P.W.B ASSY
37 VIDEO P.W.B ASSY
41 COMPONENT P.W.B ASSY
42 PRE-OUT P.W.B ASSY
34 INPUT P.W.B ASSY
00D 963 0155 407 DSP P.W.B ASSY 1 *
36 DSP P.W.B ASSY
1 00D 963 0149 604 WINDOW U.K. 1
1 00D 963 0138 204 WINDOW China 1
2 00D 963 0152 303 INPUT KNOB Black model 1
2 00D 963 0152 400 INPUT KNOB Silver model 1
2 00D 963 0152 507 INPUT KNOB Gold model 1
3 00D 963 0051 501 DENON BADGE Black model 1
3 00D 963 0051 527 DENON BADGE Silver model 1
3 00D 963 0051 514 DENON BADGE Gold model 1
4 00D 963 0051 310 LED LENS 2
5 00D 963 0152 604 VOLUME KNOB Black model 1
5 00D 963 0152 701 VOLUME KNOB Silver model 1
5 00D 963 0152 808 VOLUME KNOB Gold model 1
6 00D 963 0152 905 SELECT KNOB Black model 1
6 00D 963 0153 001 SELECT KNOB Silver model 1
6 00D 963 0153 108 SELECT KNOB Gold model 1
7 00D 963 0150 004 FRONT PANEL Black model 1
7 00D 963 0150 101 FRONT PANEL Silver model 1
7 00D 963 0150 208 FRONT PANEL Gold model 1
8 00D 963 0151 809 RCA COVER U.K. (Black model) 1
8 00D 963 0151 906 RCA COVER U.K. (Silver model) 1
9 00D 963 0151 304 FRONT FRAME Black model 1
9 00D 963 0151 605 FRONT FRAME Silver model 1
9 00D 963 0151 401 FRONT FRAME Gold model 1
10 00D 963 0137 807 STANDBY LENS 1
11 00D 963 0140 001 STANDBY BUTTON Black model 1
11 00D 963 0140 108 STANDBY BUTTON Silver model 1
11 00D 963 0140 205 STANDBY BUTTON Gold model 1
