Denon AVR-2808 Owner's Manual


Getting Started Connections Playback Remote Control Multi-Zone Information Troubleshooting
ENGLISH
Audio Input Signal
Shows information about audio input signals.
F Menu screen F
2.Audio Input Signal
3.HDMI Information
4.Auto Surround Mode
5.Quick Select
6.Preset Station
1.Status
5.Information
Dialogue normalization function
This is automatically activated when playing Dolby Digital sources.
This function automatically corrects the standard signal level for
individual program sources.
The correction value can be checked using the STATUS button on
the main unit.
The figure is the correction value when the standard level is
corrected.
[Items to be checked]
Surround Mode
: The currently set surround mode is displayed.
SIGNAL
: The input signal type is displayed.
fs
: The input signal’s sampling frequency is
displayed.
Format
: The number of channels in the input signal (front,
surround, LFE) is displayed.
Offset
: The dialogue normalization correction value is
displayed.
Flag
: “MATRIX” is displayed if the input signal has
undergone matrix processing, “DISCRETE” if the
input signal has undergone discrete processing.
HDMI Information
Shows information about HDMI input signal and monitor.
F Menu screen F
2.Audio Input Signal
3.HDMI Information
4.Auto Surround Mode
5.Quick Select
6.Preset Station
1.Status
5.Information
a
HDMI Signal Information
The HDMI input signal information is displayed.
[Items to be checked]
Resolution Color Space Pixel Depth
s
HDMI Monitor Information
The HDMI monitor information is displayed.
[Items to be checked]
Interface Support Resolution
Auto Surround Mode
Shows information about auto surround mode settings.
The surround mode for which the last memory function was used
for the different input signal types is displayed.
F Menu screen F
2.Audio Input Signal
3.HDMI Information
4.Auto Surround Mode
5.Quick Select
6.Preset Station
1.Status
5.Information
[Items to be checked]
Analog/PCM 2CH Multi ch Digital 2CH Digital 5.1CH
Quick Select
Shows information about quick select settings.
F Menu screen F
2.Audio Input Signal
3.HDMI Information
4.Auto Surround Mode
5.Quick Select
6.Preset Station
1.Status
5.Information
For instructions on storing settings at Quick Select 1 to 3, see page
50.
[Items to be checked]
Name Input Source Input Mode Volume Level
Analog/PCM 2CH Multi ch Digital 2CH Digital 5.1CH
Preset Station
Shows information about preset stations.
F Menu screen F
2.Audio Input Signal
3.HDMI Information
4.Auto Surround Mode
5.Quick Select
6.Preset Station
1.Status
5.Information
[Input source]
TUNER
[Items to be checked]
A1 ~ G8
DOLBY DIGITAL EX
SIGNAL:Dolby Digital
fs :48kHz
Format:3/2/.1
Offset:-4dB
Surround Mode:
5-2.Audio Input Signal
480p
Color Space
RGB 4:4:4
Pixel Depth
8bits
Resolution
5-3.HDMI Signal Info.
5-4.Auto Surround Mode
[Analog][PCM]
2 CH :STEREO
[Multi ch]
:MULTI CH IN
[Digital]
2 CH :DOLBY PL II x Cinema
5.1 CH :DOLBY/DTS SURROUND
5-6.Preset Station
A1 FM 87.50M Hz
A2 FM 89.10M Hz
A3 FM 98.10M Hz
A4 FM 108.00M Hz
A5 FM 90.10M Hz
A6 FM 90.10M Hz
A7 FM 90.10M Hz
A8 FM 90.10M Hz
5-5.Quick Select
1/2
1.Quick Select 1
2.Quick Select 2
3.Quick Select 3
Setup
Operating from the main unit
When the STATUS button on the main unit is pressed, the set’s status
can be checked on the display.
1.AVR2808E2_ENG.indd 46 2007/09/28 11:41:36
