Connections Settings Playback Remote ControlMulti-zone Information Troubleshooting Specifications
t
e
y
u i
o
Q0
Q2
Q6
Q6
Q0
Q1
q
r
w
Q3
Q4Q5
Q7Q8Q7
Part Names and Functions
q SIRIUS connector ······································· (19)
w RS-232C connector ····································· (22)
e REMOTE CONTROL jacks ·························· (22)
r TRIGGER OUT jacks ··································· (22)
t DOCK CONTROL jack ································· (16)
y Speaker terminals ······································ (13)
u SIGNAL GND terminal ······························· (17)
i AC inlet ························································ (24)
o AC OUTLETS ··············································· (24)
Q0 Digital audio connectors ···················· (16 ~ 19)
Q1 HD Radio antenna terminals ····················· (20)
Q2 ETHERNET connector ································ (23)
Q3 COMPONENT VIDEO connectors ···(15, 16, 18)
Q4 HDMI connectors ········································ (14)
Q5 VIDEO / S-VIDEO connectors ············ (15 ~ 19)
Q6 Analog audio connectors ··················· (16 ~ 19)
Q7 PRE OUT connectors ···························· (22, 84)
Q8 EXT. IN connectors ····································· (21)
Rear Panel
Getting Started
To Next Page
