Denon AVR-3311CI Service Manual

Ref.No. Part No. Part Name Remarks Q'ty New
42 nsp BRACKET SUPPORTER 4010210206000S 1
z
44 963101009540S POWER TRANS E3 8200960750240S 1 *
z
44 963101009550S POWER TRANS E2 8200960750210S 1 *
z
44 963101009560S POWER TRANS SPE1C 8200960750220S 1 *
45 nsp HEAT SINK MAIN 2120211798000S 1 *
46 nsp BRACKET HEATSINK MAIN 4010214906000S 1
47 nsp BRACKET HDMI 4010214896000S 1
48 nsp SUPPORTER PCB 4070211653000S 1
49 nsp BRACKET H SINK 4010056906010S 5
50 nsp SPACER CARD 4300210062000S 1
51 nsp CUSHION BD 4050211845000S 1
52 nsp BRACKET SMPS 4010214886000S 1
53 nsp CHASSIS BACK E3 3207213516400S 1 *
53 nsp CHASSIS BACK E2 3207213516600S 1 *
53 nsp CHASSIS BACK SPE1C 3207213516700S 1 *
54 00D2051116006 TERMINAL 3790000090000S 1
55 963403011030D CABINET TOP BK 3000211736200S 1 *
55 963403011750D CABINET TOP SP 3000211736300S 1
56 963454001800D COVER HOLDER BKE2 4310213701000S
56 963454001810D COVER HOLDER SPE2,SPE1C 4310213701100S
57 963419011370D COVER SAFETY BKE2 4310215202100S
57 963419011360D COVER SAFETY SPE2,SPE1C 4310215202000S
58 nsp TAPE INLET 1220210759000S 1
59 963183011000S HD-RADIO MODULE E3 E908071010000S 1 *
62 nsp CUSHION BRACKET 4050213165000S 2
63 nsp CUSHION TOP 4050213155000S 1
64 nsp GASKET EARTH 4400210599000S 1
65 nsp BRACKET EARTH 4010215046000S 1
66 nsp GASKET EARTH 4400210609000S 1
★
67 00D2740213003 TR 2SD2560Y
Q404,Q416,Q428,Q440
Q452,Q464,Q476
J5032560Y0170S 7
★
68 00D2720174007 TR 2SB1647Y
Q410,Q422,Q434,Q446
Q458,Q470,Q482
J5011647Y0170S 7
★
69 214050011705S TR KTC3964
Q409,Q421,Q433,Q445
Q457,Q469,Q481
J502396400010S 7
70 nsp TAPE HEATSINK(ACETATE CLOTH) E2,E1C 1220210899000S 1
71 nsp WASHER 1530210292000S 2
72 nsp ACETATE TAPE for BRACKET HDMI 1220210909000S 1
73 nsp ACETATE CLOTH 6*9 1220210789010S 1
SCREWS
A nsp SCREW(+2S 3*8 B-TYPE ZNW/BH) B020030081B10S 33
B nsp SCREW(+2S 3*15 B-TYPE ZNW/BH) B020030151B10S 2
C nsp SCREW(+2S 3*8(ROUND) BK/BH) B020230083B10S 46
D nsp SCREW(+2S 3*10 B-TYPE(DOT) BK/BH) E3 B020030103B11S 48
D nsp SCREW(+2S 3*10 B-TYPE(DOT) BK/BH) E2,E1C B020030103B11S 50
E nsp SCREW(+2S 3*14 P(Φ6)+S-WASHER ZNY/HH) B018230141H11S 21
F nsp SCREW(+2S 3*17 B-TYPE ZNW/BH) B020030171B10S 3
G 00D9630048307 SCREW(+2S 4*8 B-TYPE(DOT) BK/BH) for INLET 1500040083B10S 2
G 00D9630048307 SCREW(+2S 4*8 B-TYPE(DOT) BK/BH) BK : for CABINET TOP 1500040083B10S 6
G 00D9639004012 SCREW(+2S 4*8 B-TYPE(DOT) NI/BH) SP : for CABINET TOP 1500040084B10S 6
H nsp SCREW(+3S 4*10 P+S-WASHER(ROUND)BK/BH) B028940101B11S 4
I nsp SCREW(+2S 3*8 B-TYPE BK/FH) B020030083F10S 2
P nsp SCREW(+2S 3*8 PI9.5 B-TYPE ZNW) 1500001206010S 4
Q nsp SCREW(+M 3*6 BK/BH) E3 B000030063B10S 8
Q nsp SCREW(+M 3*6 BK/BH) E2,E1C B000030063B10S 7
S nsp SCREW(+2S 3*10 B-TYPE BK/FH) B020030103F10S 2
T nsp SCREW(+2S 3*6 B-TYPE(DOT) BK/BH) E3 B020930063B10S 2
WIRES
★
101 nsp CLAMP CABLE TIE DACT-100A 4330040343010S 7
★
102 963606011190S CABLE,FLAT CARD 1.0MM 105C 1.0*16*160 N711161622490S 1
★
104 963606010490S CABLE,FLAT CARD 1.0MM 1.0*40*290 N711402912480S 1
★
105 963606011210S CABLE,FLAT CARD 1.25MM E3 : 1.25*13*80 N712130824480S 1
★
106 963606011900S CABLE,FLAT CARD 1.0MM 105C 1.0*23*610 N711236112490S 1
Personal notes:
149
