Denon AVR-3311CI Service Manual

196
Ref. No. Part No. Part Name Remarks Q'ty New
DZ1 00D9600095801 D,ZENER MTZJ6.8B K06006R844520S
RLY1 00D9630218409 RELAY BC3-12 24V 2A G680240202030S
RLY2-5 963682002440S RELAY 12V 5A SPK G680120502050S
RLY7,8 963682002440S RELAY 12V 5A SPK G680120502050S
z
F100 963652010510S FUSE T2A/250V E3 N751502001160S
z
F100 963652010500S FUSE T1.6A/250V E2, E1C N751501601160S
z
F101 963652010520S FUSE T6.3A/250V E3 N751506301160S
z
F101 963652010910S FUSE T3.15A/250V E2, E1C N751503151160S
JACK1 963643010360S TER,BOARD SCREW 6P JB-602A-02 G613602A0200YS
JACK2 963646001690S TER,BOARD SCREW 8P MST-108V1-01 G614108V1010MS
JACK3 00D9630257208 TER,BOARD SCREW 8P JB-405E(V0)-02 G612405E0200YS
JACK4,5 963643011140S TER,BOARD SCREW 2P MST-103V1-03 G611103V1030MS
z
JK100 00D2033958004 SOCKET,POWER AC INLET G4300152P0001S
L1-7 nsp COIL INDUCTOR 0.5UH D330R50000000S
z
L100 963111010230S COIL LINE FILTER LF-4ZB-E273H 27mH D320402730020S
z
RL101 963682010370S RELAY HL31-1AT-5H 5V 1A G680050102020S
z
T100 963102010240S TRANS,SWITCHING ST-4430A E060044300010S *
TR100 00D9630255802 TR 2SC KTC3199Y J5023199Y0010S
TR101 00D9630255802 TR 2SC KTC3199Y J5023199Y0010S
TR102 00D9630255802 TR 2SC KTC3199Y J5023199Y0010S
WIRE1 nsp CN,WIRE 200MM/2P L000201020150S *
WIRE5 nsp CN,WIRE 900MM/2P L000901020050S *
nsp HOLDER,FUSE CLIP F100_1 G645000050010S
nsp HOLDER,FUSE CLIP F100_2 G645000050010S
nsp HOLDER,FUSE CLIP F101_1 G645000050010S
nsp HOLDER,FUSE CLIP E2, E1C, F101_2 G645000050010S
nsp LABEL FUSE 5507000006790S
nsp LABEL FUSE E2, E1C, F101 5507000006800S
