W0W1W0Q9 Q9
te
i
Q0Q1Q2Q3Q4
Q7
oQ5Q6
q
y urw
W2
W0W1W0Q9
Q8
Q9
q RS-232C connector ····································· (21)
w TRIGGER OUT jacks ··································· (21)
e FM/AM antenna terminals
(TUNER ANTENNA) ···································· (19)
r DOCK CONTROL jack ································· (13)
t Speaker terminals (SPEAKERS) ·················· (9)
y AC OUTLETS ··············································· (22)
u AC inlet (AC IN) ··········································· (22)
i HD Radio antenna terminals
(DTU ANTENNA) ········································· (19)
o Digital audio connectors
(OPTICAL / COAXIAL) ·························· (12, 14)
Q0 WLAN ANTENNA terminal ························· (20)
Q1 ETHERNET connector ································· (20)
Q2 USB port ······················································ (18)
Q3 XM connector (SAT TU) ······························ (18)
Q4 DENON LINK connector ····························· (16)
Q5 COMPONENT VIDEO connectors ·············· (12)
Q6 HDMI connectors ·········································(11)
Q7 VIDEO / S-VIDEO connectors ···················· (12)
Q8 REMOTE CONTROL jacks··························· (21)
Q9 Analog audio connectors (AUDIO) ············ (12)
W0 PRE OUT connectors ····························· (17, 21)
W1 EXT. IN connectors ····································· (17)
W2 SIGNAL GND terminal ······························· (13)
Rear Panel
