Denon AVR-591 Service Manual

127
PCB REG_CNT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC103 00D2630553006 IC NJM7805FA J126780500130S
IC104 00D2630554005 IC NJM7905FA J126790500020S
IC105 00D2630553006 IC NJM7805FA J126780500130S
IC106 00D2630793002 IC NJM7808FA, J126780800030S
IC107 00D2630503001 IC NJM7908FA J126790800020S
IC108 963239003420S IC NJM2388F05 J126238800050S
Q100,101 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
D114 00D9630236504 D,SWITCHING AX-52 K120072140010S
D115,116 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D117,118 00D9630236504 D,SWITCHING AX-52 K120072140010S
D119-121 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D122 00D9630236504 D,SWITCHING AX-52 K120072140010S
D123 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D127-144 00D9630328409 D,SWITCHING 1N4007 K000400700010S
ZD117,118 00D9600096004 D,ZENER MTZJ33B K06033R044520S
ZD119 00D9630046202 D,ZENER MTZJ18B K06018R044520S
ZD120 00D9600128105 D,ZENER MTZJ9.1B K06009R144520S
CAPACITORS GROUP
C126 00D9630217002 C,ELECT 3300UF-M/16V D040332083010S
C127,128 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C129 00D9630217002 C,ELECT 3300UF-M/16V D040332083010S
C130 00D9630333203 C,ELECT 100UF-M/16V D040101083090S
C131 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C132 00D9630333203 C,ELECT 100UF-M/16V D040101083090S
C133 963202010440S C,ELECT 4700UF-M/25V(MHA) D040472084240S
C134 00D9630333203 C,ELECT 100UF-M/16V D040101083090S
C135 90M-OA000500R C,ELECT 4700UF-M/25V(MHA) D040472084240S
C136 00D9630333203 C,ELECT 100UF-M/16V D040101083090S
C137 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C142-144 nsp C,FILM 0.1UF-J/50V D020104167050S
C145 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C146-148 nsp C,FILM 0.1UF-J/50V D020104167050S
OTHERS PARTS GROUP
BKT101 nsp BRACKET 0.8t/SCREW 4010210196100S
CLAMP101 nsp CLAMP WIRE(SOLDER) 4330000120000S
CN10 nsp CN,WAFER 11P L109012521110S *
CN11 nsp CN,WAFER 25P L109012522510S *
CN13 nsp CN,WIRE 2MM 120MM/13P L002121130010S *
CN15 nsp CN,WIRE 2MM 120MM/4P L002121040110S *
CN100 nsp CN,WAFER 13P L109012521310S *
CN101 nsp CN,WAFER 11P L109012521110S *
