Denon AVR-591 Service Manual

PARTS LIST OF EXPLODED VIEW
zParts for which "nsp" is indicated on this table cannot be supplied.
z P.W.B. ASS'Y for which "nsp" is indicated on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts table and order replacement parts.
zThe parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Ref. No. Part No. Part Name Remarks Q'ty New
22A nsp PCB FRONT ASSY 7025HK0923023 1 *
11 - PCB FUNCTION
14 - PCB H/P
22 - PCB FRONT
23 - PDB FUNCTION_CNT
26 - PCB GUIDE_L
29 - PCB TOP_GUIDE
33 nsp PCB 5CH_AMP ASSY 7025HK0923020 1 *
50 nsp PCB AUDIO_VIDEO ASSY 7025HK0923024 1 *
53A nsp PCB REG_CNT ASSY 7025HK0923022 1 *
51 - PCB SIDE_CNT
52 - PCB REG
53 - PCB REG_CNT
57 - PCB FRONT_CNT
54A nsp PCB SPK ASSY 7025HK0923021 1 *
54 - PCB SPK
55 - PCB SMPS
56 963189009990D PCB HDMI ASSY 7025HK0923026 1 *
1 963416010570D WINDOW DISPLAY 5077212762070S 1 *
2 963412000570D KNOB FUNCTION(KD) 5080211761000SZ 1
3 00D9630362109 BADGE DENON 5630210028300S 1
4 963402010010D PANEL FRONT 3067214921000S 1 *
5 00D9630137807 LENS STANDBY 3710210503000S 1
6 nsp CUSHION SIDE 4050213095000S 2 *
7 963411002820S BUTTON-ASSY STANDBY(KD) 5098212361000SZ 1
8 963411001390D BUTTON 2KEY 5097213591000S 1
12 963419010060D COVER RCA 4317215141000S 1 *
15 963412000560D KNOB VOLUME(KD) 5080211751000SZ 1
16-1 963411003770D BUTTON BUTTON 1KEY 5097213801000S 1
17 963411003380D BUTTON CURSOR 5KEY 5097213811000S 1
18-1 963411001400D BUTTON 3KEY A 5097213601000S 1
18-2 963411001410D BUTTON 3KEY B 5097213611000S 1
19 00D9630365002 BUTTON WIN 3KEY 5097213371000S 2
20 963411003400D BUTTON WIN 3KEY C 5097213831000S 1
★
27 nsp SHEET RATING CHASSIS 1210211269000S 1 *
28 nsp HEAT SINK MAIN 2120211778000S 1 *
32 nsp BRACKET H SINK 4010056906010S 5
40 nsp CUSHION FOOT 4050211295000S 4
41 963407003330D FOOT 4000210261000S 4
42 nsp CHASSIS MAIN 3200213506000S 1 *
43 nsp SUPPORTER PCB 4070001601010S 3
44 nsp BRACKET SIDE 4010210686000S 1
45 nsp SUPPORTER P.C. 4070210192000S 1
Ref. No. Part No. Part Name Remarks Q'ty New
z
46 963101009890S POWER TRANS MAIN 8200858690350S 1 *
59 nsp SPACER CARD 4300210062000S 1
60 nsp BRACKET SMPS 4010214886000S 1 *
61 nsp PLATE EARTH USB 4470211946100S 1 *
★
63 00D9960018706 TR 2SB1560-Y
Q410,Q422,Q434,
Q446,Q458
J5011560Y0000S 5
★
64 963219003340S TR 2SC KTC3964
Q409,Q421,Q433,
Q445,Q457
J502396400010S 5
★
65 00D9960018706 TR 2SD2390-Y
Q404,Q416,Q428,
Q440,Q452
J5032390Y0000S 5
70 nsp CHASSIS BACK 3207213526300S 1 *
72 nsp STOPPER CORD AC 4380210002000S 1
z
73 00D9630292205 CORD ASSY L068125100020S 1
76 963401010050D CABINET TOP 3000211736000S 1 *
82 nsp CUSHION SCREW 4050213025000S 4 *
83 nsp CUSHION 4050213155000S 1 *
★
88 963606010490S CABLE,FLAT CARD 1.0MM N711402912480S 1 *
★
89 nsp CLAMP CABLE 4330040343010S 6
SCREWS
A nsp SCREW +2S 3*8 B-TYPE ZNW/BH B020030081B10S 22
C nsp SCREW +2S 3*15 B-TYPE ZNW/BH B020030151B10S 1
D nsp SCREW, +2S 3*10 B-TYPE(DOT) BK/BH B020030103B11S 23
E nsp SCREW +2S 3*14 P(Φ6)+S-WASHER ZNY/HH B018230141H11S 15
F nsp SCREW +2S 3*17 B-TYPE ZNW/BH B020030171B10S 3
G 00D9630048307 SCREW +2S 4*8 B-TYPE(DOT) BK/BH 1500040083B10S 6
H nsp SCREW +3S 4*10 P+S-WASHER(ROUND)BK/BH B028940101B11S 4
I nsp SCREW +2S 3*8 ZnY WASHER PI12 1500001456010S 1
P nsp SCREW +2S 3*8 PI9.5 B-TYPE ZNW 1500001206010S 2
Q nsp SCREW +M 3*6 BK/BH B000030063B10S 5
T nsp SCREW +2S 3*8(ROUND) BK/BH B020230083B10S 38
95
