Denon AVR-X1200W User Manual

Manual Setup
Perform when setting the speakers manually or when changing settings
made in Audyssey
®
Setup.
0
If you change the speaker settings after performing Audyssey
®
Setup,
you will no longer be able to select Audyssey MultEQ
®
XT, Audyssey
Dynamic EQ
®
or Audyssey Dynamic Volume
®
. (v p. 158)
0
“Manual Setup” can be used without changing the settings. Please set if
necessary.
Amp Assign
Select the power amplifier usage method to match your speaker system.
See “Speaker configuration and “Amp Assign” settings” (v p. 36)
regarding the speaker configuration and connection.
o
Assign Mode
Select how to use the power amp.
Surround Back:
Setting for 7.1-channel playback using
surround back speakers.
Front Height:
Setting for 7.1-channel playback using
front height speakers.
Top Front:
Setting for 7.1-channel playback using
top front speakers.
Top Middle:
Setting for 7.1-channel playback using
top middle speakers.
Front Dolby:
Setting for 7.1-channel playback using
front Dolby Atmos Enabled speakers.
Surround Dolby:
Setting for 7.1-channel playback using
surround Dolby Atmos Enabled
speakers.
Contents Connections Playback Settings Tips Appendix
186
Front panel Display Rear panel Remote Index

Denon AVR-X1200W Specifications

General

HDMI in	6
AC (power) in	Yes
Composite video in	2
USB ports quantity	1
Digital audio coaxial in	0
Receiver type	-
Audio output channels	7.2 channels
Total Harmonic Distortion (THD)	1 %
Power output per channel (20-20KHz@8 Ohm)	145 W
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Spotify
Product color	Black
Audio decoders	DTS-HD Master Audio
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	430 W
Connectivity technology	Wired
Optical drive included	No
Audio formats supported	AIFF, ALAC, FLAC

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	151 mm
Weight	8500 g
