Denon AVR-X1200W User Manual

ZONE2 Setup
Makes settings for audio playback with ZONE2.
0
Values set for “Volume Limit” and “Pow.On Volume” are displayed according to the
setting specified for the volume “Scale” (v
p. 157).
o
Volume Level
Set the volume output level.
Variable
(Default) :
Volume can be adjusted.
1 – 98
(–79.5 dB – 18.0 dB):
Volume is fixed at the desired level. The
volume cannot be adjusting using the
remote control unit.
o
Volume Limit
Make a setting for maximum volume.
60 (-20 dB) / 70 (-10 dB) / 80 (0 dB)
(Default : 70 (-10 dB))
Off: Do not set a maximum volume.
0
This can be set when “Volume Level” is set to “Variable”. (v p. 209)
o
Pow.On Volume
Define the volume setting that is active when the power is turned on.
Last
(Default) :
Use the memorized setting from the last
session.
Mute: Always use the muting on condition.
1 – 98
(–79.5 dB – 18.0 dB):
The volume is adjusted to the set level.
0
This can be set when “Volume Level” is set to “Variable”. (v p. 209)
Contents Connections Playback Settings Tips Appendix
209
Front panel Display Rear panel Remote Index

Denon AVR-X1200W Specifications

General

HDMI in	6
AC (power) in	Yes
Composite video in	2
USB ports quantity	1
Digital audio coaxial in	0
Receiver type	-
Audio output channels	7.2 channels
Total Harmonic Distortion (THD)	1 %
Power output per channel (20-20KHz@8 Ohm)	145 W
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Spotify
Product color	Black
Audio decoders	DTS-HD Master Audio
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	430 W
Connectivity technology	Wired
Optical drive included	No
Audio formats supported	AIFF, ALAC, FLAC

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	151 mm
Weight	8500 g
