Denon AVR-X7200W Service Manual

Check the connection environment
YES
YES
YES
YES
YES
Are the network settings of this unit correct?
Are peripheral devices such as the router and hub connected cor-
rectly?
Are the router settings correct?
Set the IP address, etc. correctly.
If the IP settings are xed, check that no
other devices have the same IP address and
that the subnet mask settings are correct.
Connect the peripheral devices correctly.
Check the instruction manual of the router
and congure the settings correctly.
Check that there are no connection restric-
tions by MAC addresses, etc.
NO
NO
NO
5. Network/Bluetooth/USB
5.1. Cannot connect to the network
Is the LAN cable correctly inserted?
Insert the LAN cable correctly and then turn
on the power again.
NO
Check the connection environment
Checking the unit
YES
YES
Can an output voltage (3.3V) to U611
(DC-DC Conv.) be conrmed?
Can a voltage (5V) be conrmed between pin 2 and pin 5 of
N6502?
Is D5V_POWER (U5001 uCOM 85pin)
"Hi" ?
The circuit of D5V_POWER between
U5001 and U611 are faulty.
The circuit around U5001 (DC-DC.
Conv.) is faulty.
The circuit between the AC inlet and N6502
is faulty. Check the SMPS PCB.
NO NO
NO
YES
109

Denon AVR-X7200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	11.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	210 W
HDMI in	8
Audio (L/R) in	7
Composite video in	5
Digital audio optical in	2
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	3
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	427 mm
Width	434 mm
Height	196 mm
Weight	17800 g
